HUA XING PCBA LIMITED
Quick Details
- Place of Origin:China (Mainland)
- Brand Name:HUA XING
- Model Number:021
- Base Material:FR-4, PTEE, aluminum
- Copper Thickness:1OZ
- Board Thickness:1.6mm
- Min. Hole Size:0.1mm
- Min. Line Width:0.075mm
- Min. Line Spacing:0.075mm
- Surface Finishing:HASL, OSP
- Color:green
3. Detailed Terms for Pcb Assembly
Technical requirement:
1) Professional Surface-mounting and Through-hole soldering Technolog
2) Various sizes like 1206,0805,0603 components SMT technology
3) ICT(In Circuit Test),FCT(Functional Circuit Test) technology.
4) PCB Assembly With UL,CE,FCC,Rohs Approval
5) Nitrogen gas reflow soldering technology for SMT.
6) High Standard SMT&Solder Assembly Line
7) High density interconnected board placement technology capacity
4.Technical capacity
PCBA Technical Capacity
SMT |
Position accuracy:20 um |
Components size:0.4×0.2mm(01005) —130×79mm,Flip-CHIP,QFP,BGA,POP | |
Max. component height::25mm | |
Max. PCB size:680×500mm | |
Min. PCB size:no limited | |
PCB thickness:0.3 to 6mm | |
PCB weight:3KG | |
Wave-Solder |
Max. PCB width:450mm |
Min. PCB width: no limited | |
Component height:Top 120mm/Bot 15mm | |
Sweat-Solder |
Metal type :part, whole, inlay, sidestep |
Metal material:Copper , Aluminum | |
Surface Finish:plating Au, plating sliver , plating Sn | |
Air bladder rate:less than20% | |
Testing |
ICT,Probe flying,burn-in,function test,temperature cycling,AXI – 2D and 3D automated X-ray inspection, AOI – automated optical inspection |
5.PCB Material Supplier
1. Our professional engineering team can put your project into production in a short time. Sample pictures and BOM are needed to make customized products
2. We can supply CAD and Pro-E designed precision moulds. Moulds can be designed and manufactured according to customers' requests or samples. Plastic injection processing available.
3. We have advanced equipment for through-hole and SMT DIP COB cable assembly.
4. ROHS compliant and lead-free process.
5. In-circuit, functional tests& burn-in tests, full system test
6. High output to guarantee prompt delivery.
6.Packaging
7.Certifications
8.PCB or PCB Assembly files requests
1)Gerber files of the PCB Board
2)BOM(Bill of material) for assembly
To short the lead time,please kindly advertise us if there is any acceptable components substitution.
3)Testing method & Test fixtures if necessary.
4)programming files & programming tool if necessary
5)Schematic if necess
9.Our factory
10.Customer visit
2) Cloning and Copy service
3) Prototyping service
4) Mold making and plastic Injection
5) FPC making
6) Cable and wire Assemblies
7) Supply Chain service
8) other OEM service
12,Shippment
More details about us, kindly scan website:
If you send us your Gerber Files , PCB specification and BOM, we will quote for you within 12 hours.
Thanks in advance !
If there are any inquiries please don't hesitate to contact us, we'll response in 24 hours!
