HUA XING PCBA LIMITED
1.Specifications
1. We offer One-shop PCAB/PCB manufacturing service
2.10 year of turnkey ODM/OEM experience
3. We can provide F4B,F4BK, Teconic,Arlon,Rogers materia PCB
4. Timely customizations PCBs and PCBAs
2.Picture of product
3. Detailed Terms for Pcb Assembly
Technical requirement:
1) Professional Surface-mounting and Through-hole soldering Technolog
2) Various sizes like 1206,0805,0603 components SMT technology
3) ICT(In Circuit Test),FCT(Functional Circuit Test) technology.
4) PCB Assembly With UL,CE,FCC,Rohs Approval
5) Nitrogen gas reflow soldering technology for SMT.
6) High Standard SMT&Solder Assembly Line
7) High density interconnected board placement technology capacity
4.Technical capacity
PCBA Technical Capacity
SMT |
Position accuracy:20 um |
Components size:0.4×0.2mm(01005) —130×79mm,Flip-CHIP,QFP,BGA,POP | |
Max. component height::25mm | |
Max. PCB size:680×500mm | |
Min. PCB size:no limited | |
PCB thickness:0.3 to 6mm | |
PCB weight:3KG | |
Wave-Solder |
Max. PCB width:450mm |
Min. PCB width: no limited | |
Component height:Top 120mm/Bot 15mm | |
Sweat-Solder |
Metal type :part, whole, inlay, sidestep |
Metal material:Copper , Aluminum | |
Surface Finish:plating Au, plating sliver , plating Sn | |
Air bladder rate:less than20% | |
Testing |
ICT,Probe flying,burn-in,function test,temperature cycling,AXI – 2D and 3D automated X-ray inspection, AOI – automated optical inspection |
5.PCB or PCB Assembly files requests
1)Gerber files of the PCB Board
2)BOM(Bill of material) for assembly
To short the lead time,please kindly advertise us if there is any acceptable components substitution.
3)Testing method & Test fixtures if necessary.
4)programming files & programming tool if necessary
5)Schematic if necess
6.Sample order
1.single or double layer board (0.6/0.8/1.0/1.2/1.6mm) with HASL
5*5cm with 10pcs only need 10$ ;10*10cm with 10pcs only need
Notes: No any special tech requirements
About Film: 2 layers board need 6pcs Films
4 layers board need 8pcs Films
6 layers board need 10pcs Films
If the size of board is not 5*5cm and 10*10cm then should add engineering cost
and board cost ,film cost(16usd+0.01usd/cm²+0.01usd/cm²)
For example: Making an 2layers board samples, Thickness of board is 1.0mm ,S-
ize is 11*12cm then how much should I pay ?
16(engineering cost )+11×12×0.01×10(pcs)(board cost)+0.01 ×6×11×12
(film cost)=37.12usd
7.Packaging
8.Certifications
9.FAQ
FAQ:
1.What service can you provide?
We can provide PCB gerber file design,Copy and Clone,OEM and ODM service.
Not only produce PCB,PCB Assembly,but also Plastic Enclosure,and Complete products
2.Are my design files secure when I send them to you?
Your files are held in complete safety and security while Hua Xing PCBA Limited is in possession of them. Your files are never shared nor will any third parties have access to your design files. Since they are your property, we respect the copyright of your files. The customer controls the disposition of these files per your requirements and written approval.
3.For small quantity orders, can you produce prototype PCBs?
Yes. Hua Xing PCBA Limited has the capability to produce PCBs in any amount. But,the greater the quantity, the greater the cost savings.
4.Do you have an order minimum?
We accept order with as low as a quantity of 1 (piece or panel).
5.What is the standard thickness of laminate that Hua Xing PCBA Limited uses?
1.6 mm (0.063″)
6.What are all your options for laminate thickness?
We can handle the following non-standard thicknesses: 0.2mm (0.0079″), 0.4mm (0.016″), 0.6mm (0.024″), 0.8 mm (0.032″), 1.0 mm (0.04″), 1.2mm (0.047″), 2.0mm (0.079″), and 2.3mm (0.091″).
7.Do you have the capability of manufacturing high frequency materials? Rogers?
While expensive, we can manufacture these materials. Contact us for pricing prior to placing an order.
8.What options exist for the thickness of copper?
0.5 oz, 1.0 oz, 1.5 oz, 2.0 oz, 2.5 oz, 3.0 oz, 3.5 oz, 4.0 oz, 4.5 oz and 5.0 oz.
9.What are the color options for PCB solder masks?
Green, black, blue, red green, yellow and white
10.What are the options for surface finishes?
The options include HASL, Immersion gold, Immersion tin, Immersion Silver, OSP, and HASL lead free. Call for other options.
11.What file formats do you accept for PCB assembly?
Gerber and CAM Auto CAD DXF, DWG formats.
10.Our factory
11.Customer visit
12.How to pcb quotation
Starting Requirements and Specifications
(1) Gerber data for all artwork layers
(2) Aperture list or lists for all layers
(3) Drill file in Gerber or Excellon format
(4) Drawings: Print should be hard copy or Gerber HPGL or DXF format
More details about us, kindly scan website:
If you send us your Gerber Files , PCB specification and BOM, we will quote for you within 12 hours.
Thanks in advance !
If there are any inquiries please don't hesitate to contact us, we'll response in 24 hours!
