Product Details
| Place of Origin | Shandong, China | Brand Name | Cost-effective noise rfi/rf filter top quality | |
| Model Number | BT7104P-0.5 |
Product Description
Cost-effective noise rfi/rf filter top quality | |
Features & Applications
- Effectively suppress the noise interference on line to line and line to ground.
-Plastic or metal cover, specially designed for PCB.
-Small size, compact structure, easy to install and cost-effective.
-Suitable for exchange machine, alarm, controller, LCD, satellite TV system and other ultra-small devices.
- Certification :
| |
Technical data
Rated Voltage | Rated Current@40℃ | Test Voltage | Climatic Category | Operating Frequency | |
110/250VAC | 0.5 – 6A | Line-line | Line-ground | 25/085/21 | 50/60Hz |
1500VDC | 1500VAC | ||||
Product Overview | |||
Part No. | Rated Current@40℃ | Leakage Current 250VAC/50Hz@20℃ | Termination |
BT7104P-0.5 | 0.5A | <0.5mA | O |
BT7104P-1 | 1A | <0.5mA | O |
BT7104P-3 | 3A | <0.5mA | O |
BT7104P-6 | 6A | <0.5mA | O |
BT7204P-1 | 1A | <0.5mA | O |
| BT7204P-3 | 3A | <0.5mA | O |
| BT7200P-1 | 1A | <0.5mA | O |
| BT7200P-3 | 3A | <0.5mA | O |

Certifications | |||
After-sale Service | |||
You can contact our after-sale service dept. within 24 hours a day by by telephone, email or online.
|
Packing & Delivery | ||
Delivery Detail:
- The lead time will be within 14 to 30 working days after your deposit.
- We could provide transport service by sea or by air, including to-door service. We have our channel discount with many express companys.
Packaging Details:
1. safe export carton with strong partition board to aviod hit 2. non fumigation pallet 3. carton+pallet to be safe enough 4. 2 or 3 layers corrugated inner carton box; wooden box available upon request with extra cost 5.customized designs for packings are also warmly welcomed.
| ||
Our Company | |
Idpro put a high value on developing and applying new sci-tech. We have our own R&D dept. so to ensure that we bring new-tech into our producing in time. Our service covers manufacturing, marketing and technical consulting of products in EMC field.
We could provide you:
- Military and civilian EMI filters - OEM & ODM products - Ideal EMC solutions and reliable EMC practice experience - High-efficiency EMC products
| |
|
