COMPANY DESCRIPTION
Our company is a professional manufacturer of roll profile high-frequency welded pipe equipment, four roller cold rolling mill, high-speed shear equipment, precision cold forming equipment, stainless steel welded pipe equipment and all kinds of complicated cross-section. It is one of the earliest domestic special factories that are engaged in making welded pipe equipment in China.
TECHNICAL PARAMETERS
Specification: |
Φ245×10 |
Pipe Diameter: |
Φ89~Φ245mm |
Pipe Thickness: |
3~12mm |
Pipe Materials: |
Q195,Q215,Q235 |
Welding Speed: |
10~30M/Min |
WELDING SPEED SCHEDULE
|
Thickness OD |
3.0 |
4.0 |
5.0 |
6.0 |
8.2 |
Φ76 |
40 |
40 |
30 |
-- |
-- |
Φ89 |
40 |
40 |
30 |
25 |
-- |
Φ114 |
40 |
40 |
28 |
25 |
-- |
Φ165 |
40 |
35 |
28 |
25 |
20 |
Φ180 |
40 |
35 |
28 |
25 |
20 |
Φ219 |
40 |
30 |
28 |
25 |
20 |
API model mainly produces high level steel pipes, such as delivery pipe of petroleum and natural gas, oil well casing and so on. The requirements for material and quality are very strict. The mill is equipped with section equipment and technological equipment, such as IF annealing, air-cooled roll table, ultrasonic inspection, high pressure hydraulic pressure testing machine and so on.
National standard model mainly produces the steel pipe, such as water-gas pipe, structure pipe and so on.
Forming and sizing unit uses combination of FF forming and FFX forming to produce steel pipes through HF induction welding. Heating method uses HF induction or contact welding, i.e. steel pipe fed into the mill is formed into pipe profile by forming rolls. With skin effect and proximity effect of high frequency current, induced electricity is concentrated onto the bonding surface of the pipe profile fringe to heat it up quickly to welding temperature, and finishes pressure welding when pipe fringes squeezed together by squeezing roll. After normalizing, cooling, sizing and primary straightening, steel pipe of desired size is produced.
FEATURES:
More shared rolls, easy adjustment, high quality weld seam, sturdy machine frame, easy operation and maintenance.
DELIVERY
Shipment of goods in accordance with equipment list within 8 months starting from the next day of contracting and receiving down payment.
PAYMENT TERMS
30% advance payment after signature of contract, 30% progress payment after two months, and 30% before delivery. Remain amount to be paid within 1 year after delivery.
PACKING
electric control part packed in wooden case, remaining nude packed.
AFTER-SALES SERVICE
The supplier will send technical persons to buyer’s site to carry out installation & testing and provide technical support. Relevant expenses shall be borne by the buyer. During testing, the buyer shall provide required plant building & equipment, testing material and manpower support.
1. PAINTING
Equipment surface shall be coated with antirust paint. Paint color can be decided by the buyer or by the supplier on his discretion.
2.FOUNDATION WORK
The supplier will provide the buyer with foundation drawing of the equipment, with construction and supervision of foundation at the buyer’s own responsibility.
The client shall prepare plant building, equipment foundation, and cooling water pool as per equipment data provided by the supplier. Necessary installation apparatus (lifting rig, tools), installation accessories (wires, conduits, water pipes), and helping labors shall be arranged by the client.
The client shall provide water supply, power supply, and air supply to machine interface.
3.WARRANTY
The warranty will cover a period of one year starting from delivery for machines under normal operation conditions (Force Majeure excluded).
QUALIFICATION CERTIFICATE
