Full Automatic Pet Bottle Unscrambler Machine/Sorter

Full Automatic Pet Bottle Unscrambler Machine/Sorter photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Beverage
Packaging Type:
Bottles
Payment & Shipping
Payment Methods:
Port of Shipment:
shnghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Beverage
Packaging Type Bottles
Packaging Material Plastic
Automatic Grade Automatic
Driven Type Electric
Place of Origin Jiangsu, China
Brand Name kingmachine
Model Number ZSJ
Power 4.5kw

Specifications

Pet Bottle Unscrambler
1.Material :SUS304
2.Capacity:8000-3000bph
3.Full automatic
4.Beverage machinery

pet Bottle Unscrambler

Full Automatic pet Bottle Unscrambler Machine/Sorter

    The machine is used in ordering disordered polyeter bottles, the disordered bottles are carried into the storing bottle Section of the ordering bottle machine, with the help of the pushing force of the rotating disk, the bottle are ordered into Bottle mouth-up-position and are carried into the next process with the air-transfering type conveying bottle system.
High speed operatin, easy to combine with all kinds of filler or filling prodution line.



Specifications:
1) Suitable for unscrambling disordered polyester bottles
2) Aligns bottles and discharges them by vacuum conveyor
3) PLC program controlled
4) Automatic.
5) High speed operation
6) Easy to combine with all kinds of fillers or filling production lines



 Technical parameters:

Model
LP-1
LP-2 LP-3

Production capacity(bph)

8000-12000

12000-18000

18000-30000

The pressure of gas source(Mpa)

0.7

0.7

0.7

Gas Volume(m3/min)

0.5

0.6

0.7

Power(kw)

2.2
4.4 5.5

To adapt to bottle-type(mm)

Bottle DriveΦ50-Φ90,Bottles of high -150-290

Dimensions(mm)

Φ2500*2660*2000

Φ2650*3300*2200

Φ3710*4660*2390

Machine weight(kg)

3500
4000 6000





Full Automatic Pet Bottle Unscrambler Machine/Sorter



                Bottle  Unscrambling  Machine



Full Automatic Pet Bottle Unscrambler Machine/Sorter



                   Bottle  Unscrambling  Machine





Full Automatic Pet Bottle Unscrambler Machine/Sorter



                Bottle  Unscrambling  Machine
