model |
CBM-AI |
CBM-AII |
CBM-AIII |
Measuring method |
Single-mouth gross weight |
Double-mouth gross weight |
Three-mouth gross weight |
Packing accuracy |
1% |
||
Measuring speed |
250-400bag/h |
350-700bag/h |
500-1000bag/h |
Packing range |
10kg-50kg |
||
Packing form |
Valve mouth |
||
Air pressure |
0.5MPa |
||
power |
AC220V 50HZ |
||
Material size |
<5mm |
||
Weighing controller model |
CI-1560A |
||
Working temperature |
temperature:-20°C-45°C relative humidity:95% |
||
Max-power |
0.1KW |
0.2KW |
0.3KW |
Gas consumption |
0.7m2/min |
1.4m2/min |
2.1m2/min |
Overall dimension mm |
650*1270*2000 |
1300.1270*2000 |
1950*1270*2000 |
Self weight |
About 600kg |
About 1200kg |
About 1800kg |
Powder Packing Machine
Specifications
Open style powder packing machine
1.high packaing speed
2.accurate measurement and dust free
3.easy to control
Open style powder filling machine
Production Introduction
The powder packing machine for powder mainly by the quota weighing system, delivery belt and the sealing machine, the bag sewing closer, the conveyor belt in advance and so on composes.(Customer can choice the sealing machine and the bag sewing closer to meet their product need).
Main specification
Model |
JKF-159CH |
Packing weight |
1-60 |
Packing accuracy |
3-5(25kg) |
Packing speed |
4kw |
Powder |
P≥0.6Mpa,Q≥0.4m³/min |
Air consumption |
800x1400x1850mm |
Weight |
480kg |
Overall dimension |
JKF-159 |
