CNHTC's mine dump masterpiece HOWO mine bullies-peak, the car completely Out of the existing tipping design concept, completely according to mine working characteristics new development, Suitable for all kinds of open-pit mine, reclamation, steel plant, water and electricity construction site, wharf bad environment Workplaces, in the area the short distance transport business.
1. The unilateral skinned skeleton structure Double ring beam The top "well" word structure Overall foam, heat insulation, noise reduction.
2.Engine power :371Ps_420Ps
| Truck model | ZZ5507VDNB34400 | ZZ5504N3640AJ | ||
| Sale code | HV7/336/K34/6× 4D | HV7/336/K36/6× 4D | ||
| Size parameters | Overall dimension(mm) | Rectangular box | 7760× 3000× 3425 | 8060× 3000× 3425 |
| Mining box | 7960× 3000× 3425 | 8260× 3000× 3425 | ||
| Dimension in container(mm) | Rectangular box | 5100× 2800× 1500 | 5400× 2800× 1500 | |
| Mining box | 5300× 2800× 1500 | 5600× 2800× 1500 | ||
| Wheelbase(mm) | 3400+1400 | 3600+1400 | ||
| Front/rear overhang(mm) | 1500/1460 | 1500/1560 | ||
| Min. ground clearance(mm) | 270 (Front axle) | |||
| Approach/departure angle(° ) | 25/32.5 | 28/32.5 | ||
| Weight parameters | Total weight/Max. rated contained quality(kg) | 10500/50000 | ||
| Performance parameters | Max. speed(km/h)/Max. gradeability(%) | 85/69/34/41 | ||
| Engine | Mode | WD615.95 | ||
| Rated engine power(kw/rpm) | 247/2200 | |||
| Max. torque(N. m/r/min) | 1350/1100~1600 | |||
| Fuel-rate(g/kw. h) | 192 | |||
| Clutch | 430 diaphragm spring clutch A-type | |||
| Gearbox | Mode | HW18710 | ||
| Ratio | 14.28 10.62 7.87 5.88 4.38 3.27 2.43 1.8 1.34 1.00 13.91(R1) 3.18(R2) | |||
| Cab | HOVA cab, double hydraulic lock, max. angle 50° | |||
| Tire | 13.00-20 (Option: 14.00-20-20 ) | |||
| Brake system | Driving brake: dual circuit brake; Parking brake: spring energy air cut brake; Assist brake: engine exhaust brake | |||
| Electric system | single line, 24V minus earth | |||
| Fuel tank | 400L | |||
There are many types of dump trucks in our company, we will provide reasonable products for you according to your working conditions
Thank you for looking my products .
Our company are specilalized in sinotruk for more than 20 years .
We can provide you the best trucks , best price and best servics .
We are your best choice .
If you have any questions , you can contect me and I wll give you the
detailed information.
