Bearing Button Fiber Laser Marking Machine
- 100 Set / Sets per Month
- qingdao
- T/T Credit Card
Product Details
| Condition: | New | Laser Type: | Fiber Laser | CNC or Not: | Yes |
| Cooling Mode: | Air Cooling | Control Software: | EZCAD | Graphic Format Supported: | AI, BMP, DST, DWG, DXF, DXP, LAS, PLT |
| Working Accuracy: | 0.003mm | Place of Origin: | Shandong, China | Brand Name: | YUNNENG |
| Model Number: | YN-20 | Power(W): | 20W | Certification: | CE |
| After-sales Service Provided: | Engineers available to service machinery overseas |
Packaging Details
plywood case to protect portable fiber laser marking machine well
Product Description
Bearing Button Fiber Laser Marking Machine
Product Description
1. Ink and paint; phone battery labels, panels, phone key-press, small daily necessities ,accessories and so on.
2. Ceramics, EP materials; marking of electronic component package, IC, etc.
3. Plastic products; mark device shell, electronic products, LOGO, and other numerical orders
4. Metal and its surface; Stainless steel, copper, aluminum and oxidation, electroplating; used in marking hardware, daily necessities, electric cladding, Phone case etc.
5. Keyboard and keystoke; Fine Marking of keyboard and keystoke
Model | YN10 | YN20 | YN30 | |
Laser Power | 10W | 20W | 30W | |
Laser Wave length | 1064nm | |||
Q-frequency | 20KHz~30KHz | |||
Divergence | 0.3mard | |||
Marking Range | 110*110mm /175*175mm | |||
Minimum Line Width | 0.02mm | |||
Minimum Character | 0.15mm | |||
Marking Depth | 0~0.5mm | |||
Engraving Line Speed | ≤7000mm/s | |||
Repeatability Accuracy | ±0.001mm | |||
Beam Quality | M2:1.2~1.8 | |||
Marking Format | Graphics,Text,Bar Codes,Two-dimensional Code, Automatically Marking theDate,Batch Number, Serial Number,Frequency,etc. | |||
Graphic Format Supported | bmp,jpg,gif,tga,png,tif,ai,dxf,dst,plt,etc. | |||
Working Voltage | 220V±10%/50Hz/4A | |||
Unit Power | <0.5kw | |||
Use of the Environment | Clean and Dust Free or Dust less | |||
Working Condition:Humidity | 5%-75%,Free of Condensed Water | |||
Laser Module Life | >100000hours | |||
Optional Marking Area | 50mm*50mm / 100mm*100mm / 200mm*200mm | |||
Optional (Not free of charge) | Rotary Device, Moving Table, other customized Automation | |||
Detailed Images
Samples Show
Portable fiber laser marking machine Main Features
2.Maintenance Free, save equipment and worker cost;
3.Imported Galvonometer, Higher precision,faster speed;
4.Higher photoelectric conversion efficiency, Low power consumption;
5.Red light preview, more accurate and reduce positioning time;
6.Laptop with Powerful marking software;
7.User friendly software interface, easy operation;
8.Set and deal different layers graphic separately;
9.Support PLT,PCX,AL,DXF, BMP,JPG formats file;
10.Compatible AutoCAD,CorelDraw,Photoshop etc software Automatic serialization,date coding letter, symbol, pattern, figure, image, bar code, 2D code auto arrangement and amendment.
Our Services
Pre-Sales Service
1.Inquiry and consulting support.
2.Sample testing support.
3.View our Factory.
After-Sales Service
1.Training how to instal the machine, training how to use the machine.
2.Engineers available to service machinery overseas.But the fee should be paid by the buyer
One year to guarantee the total machine
