smart cnc router for stone AG1212

Specifications

stone cnc router
1.CE & ISO9001
2.DSP Control
3.Stepper Motor
4.Taiwan Hiwin Linear Rail

smart cnc router for stone AG1212

Note:we are the machine manufacturer,so we can supply you competitive price & best quality machine.



Standard Features:



1. Three axises adopt imported linear orbit, two line sliding track, heavy loading, stable working, high precision, longlife time



2. Whole seamless weld steel structure, not easy to distort, the table back lining is armor plate, good rigidity, the machine can bear 1 MT at least.



3. Constant power spindle and motor, strong cutting capacity, high efficiency,



Well compatibility, compatible software CAD/CAM, such as Type3, Artcam, Castmate, Wentai, CorelDraw



4. Double direction cutters cooling system can prolong the life time of using.



Technical-parameters:



NO.	Description	Parameter
1	X,Y,Z Working Area	1200*1200*250mm
2	X,Y,Z Traveling Positioning Accuracy	±0.03/300mm
3	X,Y,Z Repositioning Positioning Accuracy	±0.05mm
4	Lathe Structure	Welded Structure
5	X, Y Structure	TBI Ball Screw Transmission
6	Z Structure	TBI Ball Screw Transmission
7	Max. Consume power	6.5Kw
8	Max. Rapid Travel Rate	10000mm/min
9	Max.Working Speed	6000mm/min
10	Spindle Power Motor	3.0KW Chinese water-cooling spindle
11	Spindle Speed	0-24000RPM
12	Working Mode	Stepper
13	Working Voltage	AC220V/50/60Hz
14	Command	G Code, *uoo, *mmg, *plt
15	Operating System	DSP System
16	Interface	USB
17	Flash Memory	128M
18	Collet	ER11
19	X,Y Working Delicacy	<0.01mm
20	Software	Type3 software, Wentai software,Artcam software
21	Running Circumstance	Temperature: 0°C~45°CRelative humidity: 30%~75%
22	Packing Size	2130*2000*1750mm
23	Net Weight	780KG
24	Gross Weight	850KG
25	Optional	Air-cooling spindle Servo motor Water tank Vacuum table Gear transmission(Y axis two motors drive)



Parts Display:



Samples:





Package:

Packed with free-fumigation wooden case,more safer and environmental

protection during transportation.





Delivery Term:



1.FOB Qingdao/Tianjin/Shanghai



2.EXW



3.CIF+Destination port





Why some clients choose us?



We will provide the user a CD to study the machine installation and commissioning

Our technicists can give user online guide.

The user can call or email us any problems at any time.

One year warranty for machine maintenance, for equipment maintenance over the warranty period is clearly marked.
