FCC,Rohs 4 Ports Fiber Optic Media Converter 10/100M 4 Ports Fiber Optic Media Converter

FCC,Rohs 4 Ports Fiber Optic Media Converter 10/100M 4 Ports Fiber Optic Media Converter thumbnail-1
FCC,Rohs 4 Ports Fiber Optic Media Converter 10/100M 4 Ports Fiber Optic Media Converter photo-1
US$ 1 - 79 MOQ: 1 Piece
Key Specifications
Get Latest Price
Products Status:
Stock
Ports:
Other, ≤ 8
Transmission Rate:
10/100Mbps
Contact Supplier Request Quote Chat Now
APT Prosper Technology Co., Ltd.
Gold Verified Supplier
5Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Products Status Stock
Ports Other, ≤ 8
Transmission Rate 10/100Mbps
Function LACP, POE, QoS, Stackable, VLAN Support
Communication Mode Other, Full-Duplex & Half-Duplex
Certification FCC,Rohs poe switch
Switch Capacity 6G 4 ports fiber optic media converter
Brand Name Apttek 4 ports fiber optic media converter
Model Number Apt-1104F-S 4 ports fiber optic media converter
Place of Origin Guangdong, China

FCC,Rohs 4 ports fiber optic media converter 10/100M 4 ports fiber optic media converter

Product Description

 Features:

Comply with IEEE802.3, IEEE802.3u, IEEE802.3af / at other standards

Support MDI / MDIX auto- negotiation

Ultra-low latency data transmission, completely transparent to the network protocol

Integrated 1K MAC address table, MAC automatic learning and creating the table

Support spanning tree protocol

Back pressure half-duplex flow control and full-duplex flow control pause frames to prevent the loss of data frames

Support hot-swappable, plug and play

Built-in lightning protection circuit

Maximum Poe power: each port maximum 13W, Poe maximum reach distance 100m;

MTBF time>50,000 hours



Connect diagram

FCC,Rohs 4 ports fiber optic media converter 10/100M 4 ports fiber optic media converterFCC,Rohs 4 ports fiber optic media converter 10/100M 4 ports fiber optic media converter



Item

Specification/Term

1

Item number

2000 series

1000 series

2

Standard

IEEE802.3u,,IEEE802.3ah,IEEE802.3z/ab,

IEEE802.3af/at

IEEE802.3 ,IEEE802.3u,. IEEE802.3af /at

3

Poe power supply

Maximum power 13W, Maximum

transmission distance 100m, method

of power supply 1/2(+) .3/6 (-)

Maximum power 13W,Maximum

transmission distance 100m, methods of

power supply 1/2(+) .3/6 (-)

4

Transmission speed

10M/100M/1000M auto-negotiation

10/100M auto-negotiation

5

Transmission mode

half/full duplex (auto-negotiation)

half/full duplex (auto-negotiation)

6

Conversion mode

full speed forward

full speed forward

7

MAC address

8K

1K

8

Data package length

1632(10K)Bytes

1552(2048)Bytes

9

Time-delay

9.6us

9.6us

10

Bit error rate

<1/1000000000

<1/1000000000

11

MTBF

50,000 hour

50,000 hour

12

Power supply

AC100~265V 50/60Hz/DC48V 2A

AC100~265V 50/60Hz / DC48V 2A

13

Power dissipation

<8W

<2.5W

14

Interface

Ethernet Port:RJ45,Optical Port:SC/FC/SFP

Ethernet Port:RJ45, Optical Port:SC/FC/SFP

15

Twisted-pair

CAT-5,CAT-6

CAT-5,CAT-6  MDI/MDIX auto-negotiation

16

Multi-mode fiber

50/125,62.5/125um

50/125,62.5/125um

17

Single mode fiber

8/125,8.3/125,9/125um

8/125,8.3/125,9/125um

18

Wave Length

850nm/1310nm/1550nm

850nm/1310nm/1550nm

19

Transmission distance







1)dual fiber multi-mode

550m

2km



2)dual fiber single mode

20/40/60/80/100/120Km(optional)

20/40/60/80/100/120Km (optional)



3)single mode single fiber

20/40/60/80Km (optional)

20/40/60/80Km (optional)



4)Cat-5 Twisted-pair

100m

100m

20

Operating temperature

0°C-70°C

0~70°C

21

Storage temperature

-40~85°C

-40~85°C

22

Humidity

5%~90%  non-condensation

5%~90%  non-condensation

23

Size

See dimension pic

See dimension pic









Packaging & Shipping



Package:



Main body *1

Manual *1

Charger * 1

Warranty card *1

All this in a carton case



Delivery:



Leading time:5~15 working days

Delivery way:By air,sea and express(DHL,EMS,Ups,Fedex,Tnt)



Payment:



T/T,Paypal,Western Union

FCC,Rohs 4 ports fiber optic media converter 10/100M 4 ports fiber optic media converter
