Specifications
cnc routing machine AG2040T1.HSD air cooling spindle 3.0kwX3
2.Working size: 2000X4000X500mm
3.DSP controller
4.CE
cnc routing machine used for wood AG2040T
1.Features:
This is our new model in woodowrking machine, it is also the automatic tool change, pneumetic changing tools, high changing speed, precision, and most important with lower cost than the Linear type and round type ATC model.
2.Configuration:
Vertical support, t type gantry, vacuum table, 3.0KW HSD air cooling spindle, three air cylinders. Orginal DSP control system.
3.Parameters:
1 |
Model |
Pneumetic type AG1325T with 3 spindles |
2 |
X,Y Working area |
2000mmx4000mmX500mm |
3 |
Z Working area |
500mm |
4 |
Table axis |
3100mmx4700mm |
5 |
Max travel speed |
30000mm/min |
6 |
Max working speed |
25000mm/min |
7 |
Processing precision |
0.005mm |
8 |
Repositioning precision |
0.01mm |
9 |
Table structure |
Vacuum table |
10 |
Operation mode |
G code*.U00 *.mmg *.plt |
11 |
X,Y,Z structure |
Z ballscrew, X,Y gearwheel |
12 |
Self-consuming power |
2.1KW |
13 |
Working voltage |
AC380V 50Hz |
14 |
Spindle power |
3.0kw HSD air cooling spindle X3 |
15 |
Spindle rotating speed |
0-18000rpm/min |
16 |
Drive motor |
Step motor |
17 |
Operation system |
Orginal DSP control system |
18 |
Net weight |
2800kg |
19 |
Gross weight |
3250kg |
Parts:
Why some clients choose us?
We will provide the user a CD to study the machine installation and commissioning
Our technicists can give user online guide.
The user can call or email us any problems at any time.
One year warranty for machine maintenance, for equipment maintenance over the warranty period is clearly marked.
