Apt Best Network Switch Brands 1000M 4+1 Port Tx/Lx Network Switch Brands

Apt Best Network Switch Brands 1000M 4+1 Port Tx/Lx Network Switch Brands thumbnail-1
Apt Best Network Switch Brands 1000M 4+1 Port Tx/Lx Network Switch Brands thumbnail-2
Apt Best Network Switch Brands 1000M 4+1 Port Tx/Lx Network Switch Brands thumbnail-3
Apt Best Network Switch Brands 1000M 4+1 Port Tx/Lx Network Switch Brands photo-1
Apt Best Network Switch Brands 1000M 4+1 Port Tx/Lx Network Switch Brands photo-2
Apt Best Network Switch Brands 1000M 4+1 Port Tx/Lx Network Switch Brands photo-3
US$ 1 - 80 MOQ: 1 Set
Key Specifications
Get Latest Price
Products Status:
Stock
Ports:
Other, ≤ 8
Transmission Rate:
10/100/1000Mbps
Contact Supplier Request Quote Chat Now
APT Prosper Technology Co., Ltd.
Gold Verified Supplier
5Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen/Hongkong
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Products Status Stock
Ports Other, ≤ 8
Transmission Rate 10/100/1000Mbps
Function LACP, POE, VLAN Support
Communication Mode Other, Full-Duplex & Half-Duplex
Certification CE,Rohs,Fcc
Switch Capacity 5.6 G
Brand Name Apttek
Model Number APT-2104G1G -S
Place of Origin Guangdong, China

Apt best network switch brands 1000M 4+1 port Tx/Lx network switch brands





network switch brands application fields



Gigabit Ethernet



Fiber Channel



Switch to Switch interface



Switched backplane applications



Router/Server interface



Other optical transmission systems

Apt best network switch brands 1000M 4+1 port Tx/Lx network switch brandsApt best network switch brands 1000M 4+1 port Tx/Lx network switch brands





  network switch brands specification



Product summarize

1.follow the standard IEEE 802.3, IEEE 802.3u, IEEE 802.3X;
2. support IEEE 802.3x flow control function;
3. network port access rate 10/100/1000M, full / half duplex adaptive;
4. ultra-low-latency data transmission, network protocol is completely transparent;
5. support port VLAN, port mirroring. IPV6 port mirroring traffic 4K, MAC-based Trunking
6. effectiveness of automatic link transfer, double Tagging / QinQ
7. support the generation number and loop detection, IGMP, MLD
8. support 9720Bytes length packets;
9. 50/125um or 62.5/125um multimode fiber transmission distance up to 2km connection
10. 9/125um single-mode fiber transmission distance up to 120km connection
11.provides two SFP / FC / SC connector type, the freedom to choose SFP / FC / SC modules to achieve a single / multi-mode and different transmission distance;
12. hot-swappable, plug and play;
13. has seven LED indicators, dynamic feedback link status and fault monitoring;
14. working hours MTBF> 40 years



 network switch brands parameter



Item number

APT-2104G2G-SFP

Standard

IEEE 802.1q,IEEE 802.3u,10/100/1000 Base-T,100,Base-SX-LX,IEEE802.3ah,IEEE802.3z/ab,IEEE802.1D

Flow control

IEEE8.2.3 x port flow control and back pressure control

Transmission speed

10/100/1000 M auto negotiation

Conversion mode

Modified Cut-through,Store and forward,Converter mode

MAC address

1 K

Packet length

9720 bytes

Time-delay

9.6 μs

Bit error rate

≤10-9

MTBF

100,000 hours

Power supply

AC100~265V,50/60 Hz/DC 5V 1A

Power dissipation

<2.5 W

Connector

Electric port:RJ45,Fiber Port:SC/FC

Twisted-pair

Cat.5,Cat.6

Multi mode fiber

50/125,62.5/125 μs

Single mode fiber

9/125 μs

Wave length

850/1310/1550 nm

Reach distance



Multi mode

550 m

Single mode

20/40/60/80/100/120 Km

Cat.5 twisted-pair

100 m

Working temperature

-40~85 ℃

Humidity

5~90 %

Size

135*77*27mm



Packaging & Shipping

network switch brands package and shipping

Package:



Main body *1

Manual *1

Charger * 1

Warranty card *1

All this in a carton case



Delivery:



Leading time:5~15 working days

Delivery way:By air,sea and express(DHL,EMS,Ups,Fedex,Tnt)



Payment:



T/T,Paypal,Western Union

 Apt best network switch brands 1000M 4+1 port Tx/Lx network switch brandsApt best network switch brands 1000M 4+1 port Tx/Lx network switch brands







FAQ

 network switch brands common question

 Q1 . What your MOQ?

 A1 .1 set is ok,whatever how many you need,and we will also give you the best service.



 Q2.What certification did you get?

 A2 : Our product strict operate the ISO9001:2008 quality control system and we passed the CE,CCC,ROHS and SGS test,you can trust us.



 Q3 :What about your package and delivery,will it broke during shipping?

 A3:You don't need to worry about the package,we will use shockproof case for delivering.



Q4.What your common delivery way?

 A4:By air,sea and express(Ups,Fedex,TNT,EMS...)We will make a perfect delivery plan for you.



Q5.Tell me some detail about warrant time.

A5:We give you the promise if any question during 1 year and not cause by human factors,we will fix it.











Any question.leave me an inquiry or contact me directly.





 What's app and we chat:+86 13005471327



Skype:apt.8866
