7"Industrial Panel PC Spec | ||
| Institutions and power | Material | Magnesium alloy front panel combined PET film to achieve NEMA IP65 protection grade, all-steel box structure and a large area of the heat sink fins |
Installation | Embedded panel and VESA wall mount compatible | |
Power | 6 ~ 30V DC power supply | |
Panel Color | Black | |
Overall Dimensions | 224 × 157 × 54.2 mm (Width × Height × Depth) | |
Box Size | 208 × 141 × 48.2 mm (Width × Height × Depth) | |
| Hole size | 211 × 144 mm (Width × Height) | |
System parameters | Processor | Intel Atom 1.6GHz low-power processor, 533MHz front side bus frequency |
Chipset | Intel 945GSE&ICH7-M | |
Memory | Onboard 1GB DDR2 533MHz SDRAM | |
Disk | Support CF card | |
Show | Intel GMA950 224MB Shared Memory, Dual Display Support | |
Network | 2× RTL8111DL 10/100/1000Mbps RJ45 Ports | |
Audio | RTL ALC662 Audio Controller, LINE-Out And MIC-In Port | |
Input-output Interface | 1×DC IN Power Input Terminal | |
1×DB15 VGA Display Port | ||
1×RJ45 Network Port | ||
| 1×USB2.0 front panel ports, 2×USB2.0 ports Rear | ||
| 2×RS-232 port | ||
| CD-ROM | Optional Notebook Drive | |
Watchdog | 0 ~ 255 Seconds Programmable Settings | |
Operating System | Full Support Windows ® 2000 pro / Windows ® XP pro / Windows ® VISTA / Windows ® 7/Windows ® XPE/Linux | |
LCD Display | Size/Type | 7"TFT LCD |
Resolution | 800×480 | |
Maximum color | 262K | |
Display Area | 152.4×91.4mm | |
Reaction Time | 25ms | |
Backlit | LED | |
Backlit MTBF | 50,000 Hours | |
Brightness | 400cd/m² | |
Contrast | 300:1 | |
Lattice | 0.297×0.297 | |
Maximum Angle | (H)140/(V)120 | |
Touch Screen | Size/Type | 7 "Four-wire analog resistive |
Resolution | 4096x4096 | |
Touch Response Time | <5ms | |
Surface Hardness | 3H | |
Click To Life | 250 Grams Efforts,10 Million Times | |
Stroke Life | 250 Grams Effort, 1 Million Times | |
Transmittance | More Than 80% | |
| Environmental parameters | Operating Temperature | 0~60°C |
Storage Temperature | -20~+70°C | |
Relative Humidity | ||
| Vibration | 50 ~ 500Hz, 1.5G, 0.15mm Peak | |
Impact | 10G/Peak(11ms Sec) | |
