Cheap Bimetal Thermostat Switch

Cheap Bimetal Thermostat Switch thumbnail-1
Cheap Bimetal Thermostat Switch photo-1
Negotiable MOQ: 1000 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Reomax
Model Number:
ksd 7AM BW BR-B2D
Contact Supplier Request Quote Chat Now
Dongguan Reomax Electronic Co., Ltd.
Gold Verified Supplier
5Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen or Hongkong
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Reomax
Model Number ksd 7AM BW BR-B2D

Specifications

>bimetal thermostat switch
>Tf:45C-220C
>Ur:125V/15A 250V/10A
>Reset type:automatic
>VDE CQC UL CSA



bimetal thermostat switch

1.Rated electrical performance: AC125/250V, 5A/7.5A/10A/15A/25A
2.Open temperature: 45 °C ~~ 220 ° C (according to the customers' requirements)
3.Open temperature tolerance: ± 2 ° C; ± 3 ° C; ± 5 ° C; ± 10 ° C; ± 15 ° C.
4.On-off temperature tolerance : 5 to 150 ° C
5.Reset temperature tolerances: ± 2 ° C; ± 3 ° C; ± 5 ° C.
6.Electric Strength: Under the AC50Hz/1800V,it lasts one minute without breakdown flashover phenomenon
7.Insulation resistance: ≥ 100MΩ (DC 500V)
8.Contact resistance: ≤ 50mΩ

9.heat resistance: It is based on the material

10.Life: ≥ 100,000 cycle

Cheap bimetal thermostat switch



Some Selection Guidance of KSD bimetal thermostat switch

Cheap bimetal thermostat switch

Action temperature

Reset temperature



Action temperature

Reset temperature

45±5°C

40±6°C

130±5°C

100±15°C

50±5°C

43±6°C

135±5°C

105±15°C

55±5°C

45±6°C

140±5°C

110±15°C

60±5°C

50±10°C

145±5°C

115±15°C

65±5°C

50±10°C

150±5°C

120±15°C

70±5°C

50±10°C

155±5°C

125±15°C

75±5°C

55±10°C

160±5°C

130±15°C

80±5°C

55±10°C

165±5°C

135±15°C

85±5°C

55±10°C

170±5°C

140±15°C

90±5°C

60±10°C

175±5°C

145±15°C

95±5°C

65±10°C

180±5°C

150±15°C

100±5°C

75±10°C

185±5°C

160±15°C

105±5°C

80±15°C



190±5°C

165±15°C

The specification can also be manufactured as request.





BW45 45±5°C

BW100

100±5°C
BW50 50±5°C

BW105

105±5°C

BW55

 55±5°C

BW110

110±5°C

BW60

60±5°C



BW115

115±5°C

BW65

65±5°C



BW120

120±5°C

BW70

70±5°C



BW125

125±5°C

BW75

75±5°C



BW130

130±5°C

BW80

80±5°C



BW135

135±5°C





Part number

TF

7AM 020

65°C

7AM 021

70°C

7AM 022

75°C

7AM 023

80°C

7AM 024

85°C

7AM 025

90°C

7AM 026

95°C

7AM 027

100°C

7AM 028

105°C

7AM 029

110°C

7AM 030

115°C

7AM 031

120°C

7AM 032

125°C

7AM 033

130°C

7AM 034

135°C

7AM 035

140°C

7AM 036

145°C

7AM 037

150°C

7AM 038

155°C

7AM 039

160°C

7AM 040

165°C

7AM 336

170°C

7AM 316

175°C



   Shipping



1, We can ship goods all over the world by DHL, UPS, FedEx, TNT and EMS. The packaging is very safe and strong. Please notify me if you have any special needs.
2, It will take around 3-5 days to reach your hands



All types of Klixon thermal switches are produced in our factory. For more product informantion, please do not hesitate to ask me.



Quality insurance and warranty



>Replacement of defective products for free

>Warranty period 1 Year

 Contact me for more about bimetal thermostat switch
