Color Aluminum Coil Stock

Name: Color Aluminum Coil Stock
Brand: Jinding
SKU: 116569137

US$ 2,000 - 5,000 MOQ: 10 Tons

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

Jinding

Model Number:

JDM8000 1000

Zhejiang Shuanglin Jiate Metal Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name Jinding

Model Number JDM8000 1000

Application roofing

Thickness 0.024-1.2mm

Width 20-1500mm

Alloy Or Not Is Alloy

Grade 3000 Series

Surface Treatment Coated

Temper O - H112

Specifications

1,Thickness:0.024-1.2mm
2,Max width:1500mm
3,Coating:PE,PVDF

color aluminum coil stock

color aluminum coil stock

PE coating aluminum coil

PVDF coating aluminum coil

Glossy aluminum coil

Nacreous aluminum coil

Back coating aluminum coil

Embossed aluminum coil

Aluminum Strip

Alloy	A1100,A3003,A1050,A8011 etc
Temper	H16,H18,H14
Thickness	From 0.024mm to 1.2mm
Width	Standard width:1240mm
Width	Special width:1300mm,1500mm
Diameter	Standard dia:1200mm
Diameter	Interior dia:150mm,405mm,505mm
Weight	2.5 T/coil,3.0 T/coil
Coating	PE,PVDF,ACRYLIC
Surface	Embossed,mill finish,coated
Color	AS to code RAL
Gloss	10-90%(EN ISO-2813:1994)
Coating Thickness	PE:more than 18 micron
Coating Thickness	PVDF:more than 25 micron
Coating Hardness (pencil resistance)	More than 2h
Coating adhesion	5J(EN ISO-2409:1994)
Impact Resistance	No peeling or cracking(50 kg/cm,ASTMD-2794:1993)
Flexibility(T-bend)	2T
MEK resistance	More than 100
Advantage	1.High temperature resistant 2.Weathering resistant 3.Scrubbing resistant 4.Sound insulation 5.Acid or alkali proof 6. Fireproof 7.Light weight material is easy to construct and install
Out package	Wooden splint with export standard
Application	ACP,wall cladding,facades,roofs and canopies,ceilings,signboards,blind window,display platforms,electrical panels,etc
