Metal Welded Steel Structures H Beams for sale
- 20000 Ton / Tons per Month
- Xingang Tianjin
- T/T L/C D/P D/A Credit Card
You May Like
Product Details
| Place of Origin | Hebei, China | Grade | Other, Q235B,SM490,SS400,Q345B. | |
| Technique | Other, Hot rolled or welded | Thickness | 5-34mm | |
| Application | Building Construction, Steel structure | Length | 6-12m | |
| Standard | ASTM | Flange Width | 100~500mm | |
| Flange Thickness | 7-34mm | Web Width | 100mm-900mm | |
| Web Thickness | 5-20mm | Brand Name | SANHE | |
| Model Number | Metal Welded Steel Structures H Beams for sale |
Product Description
Metal Welded Steel Structures H Beams for sale
Name | Metal Welded Steel Structures H Beams for sale |
Material Grade | Q235B,SM490,SS400,Q345B... |
Standard | GB, ASTM, AISI, BS, DIN, JIS |
Web Thickness | 5-20mm |
Flange Thickness | 7-34mm |
Web Width | 100-900mm |
Flange Width | 100-500mm |
Length | 9m/12m or as your requirement |
Packing | In bundles |
GB H Beam Specification | ||||||
Item
| Size (mm)
| Section Dimension (mm) | Theoretic Weight (kg/m)
| |||
H | B | T1 | T2 | |||
HW | 100*100 | 100 | 100 | 6 | 8 | 17.2 |
125*125 | 125 | 125 | 6.5 | 9 | 23.8 | |
150*150 | 150 | 150 | 7 | 10 | 31.9 | |
175*175 | 175 | 175 | 7.5 | 11 | 40.3 | |
200*200 | 200 | 200 | 8 | 12 | 50.5 | |
200 | 204 | 12 | 12 | 56.7 | ||
250*250 | 250 | 250 | 9 | 14 | 72.4 | |
250 | 255 | 14 | 14 | 82.2 | ||
HM | 150*100 | 148 | 100 | 6 | 9 | 21.4 |
200*150 | 194 | 150 | 6 | 9 | 31.2 | |
250*175 | 244 | 175 | 7 | 11 | 44.1 | |
300*200 | 294 | 200 | 8 | 12 | 57.3 | |
350*250 | 340 | 250 | 9 | 14 | 79.7 | |
600*300 | 582 | 300 | 12 | 17 | 137 | |
588 | 300 | 12 | 20 | 151 | ||
594 | 302 | 14 | 23 | 175 | ||
HN | 150*75 | 150 | 75 | 5 | 7 | 14.3 |
175*90 | 175 | 90 | 5 | 8 | 18.2 | |
200*100 | 198 | 99 | 4.5 | 7 | 18.5 | |
200 | 100 | 5.5 | 8 | 21.7 | ||
250*125 | 248 | 124 | 5 | 8 | 25.8 | |
250 | 125 | 6 | 9 | 29.7 | ||
300*150 | 298 | 149 | 5.5 | 8 | 32.6 | |
300 | 150 | 6.5 | 9 | 37.3 | ||
350*175 | 350 | 175 | 7 | 11 | 50 | |
400*200 | 396 | 199 | 7 | 11 | 56.7 | |
400 | 200 | 8 | 13 | 66 | ||
450*200 | 446 | 199 | 8 | 12 | 66.7 | |
450 | 200 | 9 | 14 | 76.5 | ||
Project Show
"Shijiazhuang Sanhe Light Steel Co., LTD." is a manufacturer which is devoted to steel products and steel projects.
In order to offer the highest levels of products and service, we have engineers and designers who have more than 15 years of experience join us. In the meantime, the inspection team worked with our workers in the whole manufacturing process to assure the quality....
Production Line
We are at your Service
Ensure quality,Factory direct price,Fast delivery,OEM Service
Contact Us
- Shijiazhuang Sanhe Light Steel Co., Ltd.
- Contact nameChaowei Sun Chat Now
- Phone0086-311-85042016
- Address2203, Unit 2, Bldg. 2, Gediao Spring, No. 88, Xinshi South Road, Qiaoxi Dist.
