DT-A3A Card Punching Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
Datian
Model Number:
DT-A3A Card Punching Machine
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo port DT-A3A Card Punching Machine
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
China
Brand Name
Datian
Model Number
DT-A3A Card Punching Machine
Condition
New
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
DT-A3A Card Punching Machine1.Stable performance
2.Smart digital control
3.Productivity 1200 cards/hour
DT-A3A Card Punching Machine
Product Description
DT-A3A Card Punching Machine is used to punch A3 plastic sheet and paper sheet into cards, make ID card, poker card, bookmark, photo.
Automatic adjust sheet position by photographic sensors, then automatic feed sheet for punching. Servo motor and photographic sensor to make correct feeding position. Automatic collect punched cards into card stacker and remove the waste sheet.
technical parameter
DT-A3A Card Punching Machine
| Suitable Material | Plastic and Paper like Teslin, PVC, PET, PETG, ABS and so on |
| Punching Layout | 3*7, 3*8, 3*9, 3*10, 3*11, 3*12 |
| Punching Die | 3molds |
| Control Method | PLC and Touch Screen and Servo Motor |
| Cylinder Travel | 18mm |
| Air Source | 0.6Mpa |
| Air Consumption | 100L/minute |
| Power Source | 380V or 220V 50/60Hz |
| Oil Tank | 120L hydraulic oil |
| Work Efficiency | 15000pcs standard card per hour |
| Dimension | 2100mm*1150mm*1850mm |
| Net/Gross Weight | 850KGS/900KGS |
DT-A3A Card Punching Machine
