Specifications
1600/1400/1200G laboratory tube furnace1.1600 MoSi2,
21400 SiC,
31200 Resistance wire
Model: KJ-1600/1400/1200G laboratory tube furnace
Size: Φ60x300mm (2.5"x12")
laboratory tube furnace
Laboratory tube furnace features:
1. Maximum energy efficiency is achieved by surrounding the chamber with thermal-efficient alumina fiber ceramic insulation.
2. Heavy duty double layer structure with cooling fan. Lower teperature in outside case.
3. PID automatic control via current limiting phase angle fired the resistor, e.g. SCR(Silicon Controlled Rectifier).
4. Power control with 30 segments programmable.
laboratory tube furnace laboratory tube furnace
Laboratory tube furnace descriptions:
Chamber Size |
Φ60x300mm (2.5"x12") |
Working Temperature |
1500/1300/1100°C (continuous) |
Maximum Temperature |
1600/1400/1200°C (for short time) |
Temperature Control |
30 steps programmable and PID automatic control |
Heating Rate |
0~15°C/min (suggestion: ≤10°C) |
Temperature Accuracy |
+/-1°C |
Heating Element |
MoSi2 / SiC / Resistance wire |
Working Voltage |
AC 220V, Single Phase, 60/50 Hz (or according to your requirement) |
Max. Power |
4 KW |
Note: there are different chamber sizes for your choice.
laboratory tube furnace
Package: Plastic paper inside, Polyfoam filled, Wooden box outside.
Payment: T/T, West union, etc.
Shipping and Delivery: by air/sea, in 15 days after receiving the payment.
Warranty: 1 year limited warranty on all electronic parts.
laboratory tube furnace
