1. Specifications:
Base material: hot dipped galvanized steel coil DX51D+Z EN10142 standard SGCC JIS G3302 or ASTM A653 standard
Standard: JIS G3312 CGCC, EN10143, ASTM A792
The combining force between the galvanized steel and the paint is very strong
The surface is normal spangle or polished
Thickness: 0.17-0.80mm
Width: 1000-1250mm
Zinc coating: 40- 275g/m²
Tensile strength is over 30kg/mm2
Color: RAL No. or customers' sample color
Lacquer of painting: According to customers’ need
Painting: Topside: 5microns primer+15microns polyester, Backside: 5-7microns primer epoxy
Coil ID: 508mm
Coil weight: 3-7 MT
Packing: Standard exporting seaworthy packing or according to customers’ requirement
Price Terms: FOB, CFR, CIF
Note: special requirement can be requested, small order can be negotiated
2. Application:
Nowadays, it has become the most perfect building material in construction (sandwich panel, roofing tile), transportation, manufacture, light industry, office furniture, household electric appliances, food package, and other areas all over the world.
3. Quality certificate: ISO9001
We have been using a set of production technology and advanced craft from Japan for our production line. We also hired some relevant experts to our factory to provide us very high technology and experience and production skills. We insist quality and safe are first, so that we can supply our customers with good quality and satisfactory products.
4. We have already exported our product to East and Southern Asia, Mid East, UK, Russia, Ukraine, Portugal, Greece and other European countries and Brazil, Venezuela and other southern American countries.
5. We are manufacturer of prepainted galvanized steel coil, hot dipped galvanized steel coil and tinplate in China.
Warmly welcome old and new friends in the world to have business talk with us and visit our factories.
