Specifications
A brief introduction of this machine:This machine is specialized in coating hot melt glue material such as PU, PA, PES,
Quanzhou Hengyi Machinery Co.,Ltd
Full Automatic coating machine
A brief introduction of this machine:
This machine is specialized in coating hot melt glue material such as PU, PA, PES,EVA,TPU,PO etc. those slice from hot melt glue coating cloth with high melting point steel coillaminating
The description in detail:
Coating and laminating machine is suitable for high viscosity & high melting point sheetmaterials applications, eg :A, PU, PES, EVA, TPU, PO, etc.
1 The whole machine:
Scientific design, featuring with strong rigidity & easy operation. time belt driving parts adopted, all active & passive rolls rectified by high-precision dynamic balance treatment.
CNC gantry machining center wall with a shape, complemented by sound installation process, so that machine to run a balanced, low noise, the composite material does not wrinkle and effective. Various key positions with emergency stop button to stop and open for easy handling equipment. The safe operation of Department has a clearly marked hidden, labeling and safety protection facilities. (Emergency stop buttons, protective exposure limit switch) to ensure the safe use of manipulation of staff (through the CE safety certification).
2 Coating head:
Used alloy die steel, alloy cast lip, with wear-resistant, high temperature resistance, anti-deformation and so on. The internal flow channel of uniform design is reasonable, diversion fine. With a local plastic flow regulator valve, you can glue the amount of high-precision regulator, and has to open and close function, reduce the downtime when the waste. Equipped with filter devices can be an effective filter.
3 Propulsion
Device is designed to promote strong, push away from large, easily crossing the raw materials. Its sleek design and equipped with up, down, left, right, before and after the adjustment screw, adjust the high accuracy and fast science. Thermal deformation due to coating with the automatic retractable device, to ensure that no interference caused by coating the first extensional deformation. 4 Correcting device unwinding Structure
Volume correction and reasonable structure design, the steel of solid, stable operation.
Used Mitsubishi auto tension control system can set the adjustable high-precision material Unwinding tension. Unwinding of the corrective flight control servo control from Taiwan correction device. Platform with pneumatic pick is expected to facilitate the access of raw materials to ensure the location of the next expected flatness requirements.
5 Electronic Control System
With PLC control, man-machine interface, with the speed display, plastic volume settings, retractable tension adjust your settings and other functions. Specialization, standardization wiring technology to ensure that control systems, barrier-free, operation and stability.
6 Winding Device
Winding tension with Emerson frequency vector control system of the winding tension to ensure stability, and address the uneven tension due to shutdown. Caused by winding into a roll bonding is not strong, the formation of membrane landslides.
Winding swing device adopts worm gear, through the PLC's configuration, so that rolling and passive Kun-round to maintain a suitable location, to ensure the flatness of the rolling.
NTP series of hot melt adhesive coating machine specifically dedicated sheet used: PA, PU, PES, EVA, TPU, PO and other high melting point hot melt adhesive coating sheet forming.
Application area
The device is widely used in shoe manufacturing, clothing composite, bags of hot melt film coating materials processing molding. Cosmetic industry, such as depilatory strips , nose paste, wax strips, depilatory wax strips machine, coating and lamilating , wet tissue, mouse sticking machine, sticking mouse board machine.
Key words:
Coating laminating machine/ coating laminator/ coating machine
Main Parameter
Model 300 575 1092 1575
Coating Width 300mm 600mm 1100mm 1600mm
Coating Weight 20-200g/m2 20-200g/m2 20-200g/m2 20-200g/m2
Production Speed 0-150m/min 0-150m/min 0-150m/min 0-150m/min
Magnetism Powder clutch 2.5n.m 5n.m 10n.m 20n.m
Winding Power 5.5KW MOTO 7.5KW MOTO 11KW MOTO 20KW MOTO
Winding Diameter1000mm 1000mm 1000mm 1000mm
Machine 2.5×1.1×1.5(m) 8.6×1.5×2.2(m) 9.6×2.5×2.2(m) 9.6×3.2×2.2(m)
ADVANTAGES
1.Scientific design, featuring with strong rigidity & easy operation. time belt driving parts adopted, all active & passive rolls rectified by high-precision dynamic balance treatment.
2.Main board treated by CNC processing center, with reasonable technique flow, to ensure whole machine running more stable with low noise, the material is no shrivel and high-quality.
3.Emergency stop buttons and control panels are installed on several prominent positions, convenient to operation.
4.Visible signs, marks and safeguard (emergency stop button, protecting switch) are provided on potential danger point, guarantee operators security.
