Film Stretch Wrapping Machine, Pallet Wrapping Machine, Pallet Wrapper, Stretch Wrapper, Film Winding Twist Machine

Film Stretch Wrapping Machine, Pallet Wrapping Machine, Pallet Wrapper, Stretch Wrapper, Film Winding Twist Machine photo-1
US$ 1 - 3,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Packaging Material:
Plastic
Automatic Grade:
Automatic
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Packaging Material Plastic
Automatic Grade Automatic
Driven Type Mechanical
Voltage 280v/380v
Power 1.2kw
Place of Origin Shanghai, China
Brand Name YUANXU
Model Number YK-1650F
Weight 500kg
Certification ce
After-sales Service Provided Overseas service center available

Specifications

your pallet size?
wrapping height?
weight of pallet?
need automatic film tail attach & cut?
stretch wrapping machine

Film Stretch Wrapping Machine, Pallet Wrapping Machine, Pallet Wrapper, Stretch Wrapper, Film Winding Twist MachineFilm Stretch Wrapping Machine, Pallet Wrapping Machine, Pallet Wrapper, Stretch Wrapper, Film Winding Twist Machine
YK-1650F Pallet Stretch Wrapper

Machine Performance:

Control System

OMRON PLC control system
Photo-eye pallet height sensor
0-9 separate top, bottom & up-down wrap count selectors
Photo eye sensing delay
Reinforce wrap allow more wrap on same location
Film Tension Control adjustment on the panel
015RPM variable arm speed by frequency changer
Separate variable carriage up/down speed
Separate start, reset and emergency stop buttons
Manual carriage up/down switch

Turntable

*1650mm Diameter Structural steel plate
*85mm Height (floor to top of turntable)

Turntable Drive

*0-12rpm variable turntable speed by frequency changer
*Position turntable alignment
*works under speed 1.5 kw motor with reduction gearbox, Soft start


Film Carriage System

*Powered pre-stretch system up to 250% to min film consumption
*Carriage door opens for effortless roll change and thread film
*Film delivery variable speed by separate DC Drive Motor
*Electronic film tension control adjustment on panel
*Film dancer-bar with variable speed output
   Film Stretch Wrapping Machine, Pallet Wrapping Machine, Pallet Wrapper, Stretch Wrapper, Film Winding Twist Machine
 Film carriage Drive

*Heavy duty double-chain carriage lift, calm and safety
*Film carriage variable speed by frequency changer
*Works under 0.23kw motor with reduction gear box

Technical Parameter

Wrapping Size  L500~1200mm ×W500~1200mm
Wrapping Height   L 1800mm-H 2400mm
Working Capability      20-40 Loads
Turntable Size            φ1650mm ,Height 85mm
Loadable Weight       max2000Kg
Rotary Speed                      0~12rpm
Film Carriage System   Pre-stretch Carriage System
Film Material                  LLDPE FILM Thickness17~35um
Width500mm                  Core Roller3
Up-down  Frame              Double Chains, Top Presser
Power/voltage                  Ac220v,1.5kw
Weight                            750kg
