Help CenterRolling Paper Film Stretch Packing Machine Automatically
Related Products
-
YK800FY Wrapping Packing MachineryUS$ 1 - 1,000MOQ: 1 Set -
YK1800FW Radia Rolling Paper Stretch Film Wrapping MachineUS$ 1 - 2MOQ: 1 Set
-
Reel Radial Stretch Film Wrapping Machine AutomaticallyUS$ 1 - 2MOQ: 1 Set
-
YK2000FY AUTOMATIC PACKING WRAPPERUS$ 2,000 - 3,000MOQ: 1 Set
-
YK2000FY AUTOMATIC PACKING WRAPPERUS$ 1 - 2,000MOQ: 1 Set
Used in large scales modernize manufactories, such as in food, drink, glass wares, hardware, electric appliance, paper, chemical, construction and other relevant industries.
It would wrap package, which is too heavy or too light,in cylinder shape, auto accomplish the goods input and output sensing, packing and conveying.
Product Description:
2000FY stretch wrapping machine is a machine that no arm rotates
around the load but motor drive the turntable, deliver the film around the load. These stretch wrapping systems allow loads to be wrapped while stationary on the floor. Designed for heavy or unstable loads. Film provides extra support while the products are being transported & storage to protect them from tip, spill or become damaged.
Performance:
Ø Controls :PLC controller;
Ø Photo-eye auto-height sensing;
Ø Separate 0-9 top, bottom & up-down Wrap Counter Selector; Film Tension Control adjustment on the panel;
Ø Separate start, pause and emergency stop buttons; Power on/off switch and indicator;
Ø Manual carriage up/down;
Ø Variable (mast) Speed;
Parameters
1. Turn Table Dimension φ2000 mm
2. Height of platform 460 mm as client's request
3. Roll Paper ( to be wrap ) Diameter: φ600---φ1500mm
Width: min370mm---max. 1500mm
4. Max. capacity Weight 2000kg
5. Max. Packing Size 1500*1600*1800mm
6. Turn table speed 0 -13 m/min
7. Film, Cartridge Speed 0 – 3 m / min
8. Roller Speed 0 – 15 m / min
9. Motor Power
Turntable speed 1.5 KW/220 V,AC/ 3 Phase
Film elevator 0.18 KW/220V,AC/ 3 Phase
Roller 0.37 KW/220V,AC/ 3 phase
10. capacity: 30----40pcs/hr ( It the desigh speed.And the working speed depends On worker’s proficiency
11. Machine Dimension 2895*2000*2270mm
12. Diameter Ø 180 mm – 1050 mm
13.Width 200 mm – 1,500 mm
14. Loading 30 – 400 Kg
15. Cutting Device optional
16. Power 380V 50HZ 3Phase
17.Operation Training export item- training in yuanxu factory,
