Specifications
pre-stretch film carriage. automatic device to cut the film, convey the film, plc control .INTRODUCTION
This machine have powered outfeed conveyor and powered conveyorized turntable system and is able to transport an wrapped load from the turntable to the outfeed conveyor if there is no wrapped load on the outfeed conveyor. The operator can start wrap cycle by remote control and the film is automatically attached and cut, allowing the operator to do other tasks. This arrangement eliminates the need for operators to place unwrapped loads on the floor, then pick them up again when the turntable is clear. During the machine auto wrap one palletized load, the operator can get one new unwrapped load, if there is no pallet on turntable, operator can put the new one, then take the wrapped load from the outfeed conveyor to the warehouse. Compared to a single turntable system. It increase fork lift efficiency and reduce handling time.
technical parameter
OMRON PLC control system
Photo-eye pallet height sensor
0-9 separate top ,bottom & up-down wrap count selectors
Photoeye sensing delay
Reinforce wrap allow more wrap on same location
Film Tension Control adjustment on the panel
3-12RPM variable turntable speed by frequency changer
Separate variable carriage up/down speed
Cycle pause capability
Separate start, reset and emergency stop buttons
Manual carriage up/down switch
Turntable jog button
Conveyor Jog (for each conveyor)
Dust-tight Precious Metal Slip-ring for long reliable service
Remote Control
