Pallet Wrapping Machine YK1650F-B

Pallet Wrapping Machine YK1650F-B thumbnail-1
Pallet Wrapping Machine YK1650F-B photo-1
US$ 2,200 - 2,500 MOQ: 1 Piece
Key Specifications
Get Latest Price
Condition:
New
Application:
Beverage
Packaging Type:
Cartons
Contact Supplier Request Quote Chat Now
Shanghai Yuanxu Packaging Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Beverage
Packaging Type Cartons
Packaging Material Plastic
Automatic Grade Automatic
Driven Type Electric
Power 1.35kw
Place of Origin Shanghai, China
Brand Name yuanx
Model Number YK1650F-B

Specifications

standard stretch system: 100%-150% stretch rate . wrapping height can up to 1800mm.

Specifications

PALLET WRAPPER
WORKING CAPABILITY IS 20-40 LOADS/HOUR
STRETCH FILM WRAPPING MACHINE

YK1650F-B  STRETCH FILM WRAPPING MACHINE,PALLET WRAPPER



Technical   Parameter



Turntable Diameter 1650 mm

Wrapping Height  1800mm

Turntable Height     85mm

Turntable Weight   2000 kg



Weight     600 kg

Power   1.35 kw

Voltage  220 V(single phase)

Wheel Speed    0~12rpm

pallet wrapping machine YK1650F-B

Main Performance



Programmable  Logic  Controller, Optional  winding  program, Various parameters can be adjusted

Electric Switch automatically detects goods altitude

Pre-tension automatic film feeding institutions

Turntable slowly  start, slowly breakup ,automatic reset



The  top and bottom winding can  be  controlled alone

Auto , the  hand  operation can cut  over , almost  doesn,t  need  routine  maintenance



 Film   System



Film  frame  is  dynamic  pre-tension  institutions, Pre-tension  can  reach  250%,Reduce consumption  of  membrane  quantity

Rise  and  fall  speed  of  film  frame   is  adjustable alone

Film  feeding speed  is  adjustable  ,separate DC  motor  control

Film  system  is  dynamic  institution ,a  pull  can  run



Film  frame  is  pure aluminum film  frame ,light  and  stability

choose  wear-resisting  rubber  roller ,long  operating  life

Up-down  frame is  simple  chain  structure ,stable and  reliable
