Specifications
PLC control, with self induction, layers and speed adjustable.
Pallet Stretch Film Wrapping Machine
1. PLC control
2. Load for maximum 2000kg
3. Auto convey film
4. pre-stretch film carriage. layers and speed adjustable
It is applicable to glassware, soft drink, wood, electronic, chemical, food, cosmetics, etc.
Advantages of this machine:
By wrapping the film, the appearance of packed product is more beautiful , it also do protect the cartons or cases from the moisture, dust, leaking.
Reduce the extra consume during transportation and storage .
This machine mainly adopts motor as movement parts, PLC control , self induction system which can induct the cartons or cases, easily operate , stable, reliable and endurable in use.
Technical parameters:
(L*W) Wrapping Size |
(500~1500)mm ×(500~1500)mm |
|
packing height (max)
Working Capability |
800-2000mm
20-40ctns/hour, 0-12rmp |
Worktable Size |
φ1650mm , H85mm |
Loadable Weight |
max.2000Kg |
Film carriage system |
Pre-stretch film carriage, auto convey the film |
Up-down Frame |
Double chain, up-down speed adjustable |
Control System |
PLC control, over-wrap layers adjustable, Pre-stretch film carriage |
Power supply |
1.35 kw /AC220v |
Overal dimension |
2545mm * 1650 mm *2270 mm |
Machine weight |
750Kg |
