Electrical Used Insulation Glass Fiber Banding Tape For Transformer

Electrical Used Insulation Glass Fiber Banding Tape For Transformer thumbnail-1
Electrical Used Insulation Glass Fiber Banding Tape For Transformer photo-1
US$ 0.064 - 0.24 MOQ: 1000 Meters
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
haiying
Model Number:
2841
Contact Supplier Request Quote Chat Now
Shanghai Haiying Insulation Glass Fiber Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shanghai, China
Brand Name haiying
Model Number 2841
Type Insulation Tape
Material Fiberglass
Application Other, for transformers
Rated Voltage normal
Tensile Strength 1000 N/CM

Specifications

1>MOQ:2000M
2>Supply Abilities: 3000000M/Month
3>FOBShanghai 0.08USD/M
4> SGS ISO9001:2008


  Electrical Used Insulation Glass Fiber Banding Tape  For Transformer



Electrical Used Insulation Glass Fiber Banding Tape For TransformerElectrical Used Insulation Glass Fiber Banding Tape For Transformer

 Electrical Used Insulation Glass Fiber Banding Tape For TransformerElectrical Used Insulation Glass Fiber Banding Tape For Transformer


Electrical Used Insulation Glass Fiber Banding Tape For Transformer

(2841-W)
Specifications:

1) Thermal class: F (155°, C)
2) Loss of weight at calcination: 27% ± 2%

3) Tensile strength before curing: ≥ 1000N/cm

4) Thickness (mm): 0.30

5) Width (mm): 20, 25, 30

6) Storage time: 3-- 12 months

Properties:
Type
2850-W
 2841-W
2830
Thermal class
H
 F
B
Volatile content
≤2%
 ≤4%
≤5%
Loss of weight at calcination
26%±2%
 26%±2%
26%±2%
Soluble resin content
≥90%
 ≥90%
≥90%
Tensile strength before curing
≥2000N/cm(0.33mmT)
 ≥1500N/cm(0.3mmT)
≥500N/cm(0.17mmT)
Maximum pull while banding
1500N/cm
 1000N/cm
400N/cm
Specification:
Thickness (mm)
Width (mm)
Length (M/pancake)
0.17
10,15,20,25,30
250
50
100,120
0.3/0.33
10,15,20,25,30
200
50
100
      * Special specification and package are availabe upon request, (such as spool)
Curing cycles:
Temperature (°C)
160
150
135
120
115
Time (hour)
5
6
8
16
24
      * The above times do not include the time for the workpiece to reach the curing temperature.
Storage stabili:
Storage temperture °C
10
15
20
30
Time (month)
12
10
6
3
