Oil Filter ElementGoods Description of Sinft Lube Multimantle Oil Filter Element
Oil Filter Element consists of several cylindrical filter mantles, which provide a large filtration surface with a small space requirement and allow the use of fine filter meshes. It is mainly used in:
l Various lubrication systems, e.g. marine engine, gas turbine, boiler, etc.
l Hydraulic system of rolling machine, continuous caster, etc.
l Metallurgy, petrochemical, machinery, papermaking, shipbuilding, nuclear power and coal power, and other industries related to oil filtration.
Features of Oil Filter Element
l Fixing by screw providing easy assembly, dismantle, and cleaning.
l Less pressure loss, high strength, easy cleaning, long service life, high corrosion-resistance, big operation temperature range, large filtration area, big flow, high porosity, high permeability, high dirt-holding capacity, etc.
l Cost-saving as each mantle can be changed
Specifications of Oil Filter Element
l Made of metal wire mesh
l Filtration precision: from 20μm to 120μm
l Max differential pressure: 0.35MPa
l Filtration form: parallel filtration
l Operation temperature: -25°C to 100°C
l Material: stainless steel, aluminum alloy, etc.
|
Filter element |
Model |
DN (mm) |
Flow Capacity (L/min) |
Micron Rating (μm) |
Nominal Pressure (MPa) |
Pressure loss (MPa) |
|
Initial |
Max |
|||||||
Multiple |
SFT-171×464 |
65 |
400 |
20 |
1.6 |
≤0.1 |
0.35 |
|
SFT-171×760 |
80 |
600 |
||||||
Three unite |
SFT-171×265 |
65 |
400 |
|||||
SFT-171×464 |
80 |
600 |
||||||
SFT-231×464 |
100 |
1000 |
||||||
Four unite |
SFT-420×760 |
150 |
4000 |
|||||
Five unite |
SFT-355×464 |
150 |
2500 |
|||||
SFT-355×760 |
200 |
4000 |
||||||
We will attend the Exhibition of Achema 2015, 15 - 19 June, 2015 in Frankfurt, Germany. Welcome to our Booth E55-5, Hall 6.0. Waiting for you!
Replacement of Sinft Lube Multimantle Oil Filter Element:
We have the professional filtration technology and big stock for hydraulic filter element replacement for various brands. We can help you to choose the most suitable filter element to maximize the cleaning, and also can provide the tools to remove the faults and solve the problem of cleanliness in the system.
As per your requirements, we can make superior replacements to meet your demand, such as brand of PALL, HYDAC, EPPENSTEINER, ARGO, RACOR, FAIREY, ARLON, INTERNORMEN, DOMNIC KHUNTER, etc.
With 10-year experience of filter element industry, we have our own R&D department, skilled technicians, and advanced production line for filter element. Products can be customized as per drawings and samples. We can provide you more competitive quotations with the superior quality.
Packing of Sinft Lube Multimantle Oil Filter Element can be provided as follow:
1. Neutral sea-worthy packing;
2. Each one is packed with plastic bag inside and paper box outside, then put into a carton or a wooden case;
3. According to customer's request.
For testing or inspection of Sinft Lube Multimantle Oil Filter Element, we have our own Quality Control department and testing machines. For special testing requirement, we can provide the testing results from the third party.
Application of Sinft Lube Multimantle Oil Filter Element is mainly in Oil & Gas, Marine, Metallurgy, petrochemical, machinery, shipbuilding, nuclear power and coal power, and other industries.
For transportation of Sinft Lube Multimantle Oil Filter Element, all of the above modes are available. We will choose the best way for you.
Q1. What’s Minimum Order Quantity?
A: Each item and/or color has a minimum order quantity, which would be stated in our quote sheet. Assorted items would be negotiable upon request.
Q2. What’s your packing?
A: SINFT packing or according to customer’s requirements.
Q3. Can I get some samples? How could I pay the sample payment?
A: We are honored to offer you samples. We accept the sample payment via Western Union or T/T.
Q4. How long is your Delivery Time?
A: If there is stock, the delivery time is about 5 working days after getting the payment, if no stock, 10-15 working days after the deposit.
Q5. Are you a manufacturer or trading company?
A: We are a manufacturer.
