China hot sale cutter ship
- 5 Set / Sets per Month
- Qingdao
- T/T
- 2021 Hot newest small 350 1000m3 Cutter Suction Dredger
- Hot Newest Sand Suction Dredging Boat Dredger for Sale Engineers Available to Service Machinery Overseas Customized Provided MAP
- Sand Dredging Machine 2021 Hot Newest Small 12 Inch Cutter Suction Dredger Engineers Available to Service Machinery Overseas MAP
- 2018 Hot newest small 1000m3 Sand Cutter Suction Boat
- Customized small 12 Inch cutter suction river dredging equipment
- 2022 Hot Newest Small 1200m3 Cutter Suction Dredger Manufacturer Sand Pump Suction Dredger Sand Dredging High Gold Recovery Rate
Product Details
Condition: | New | Type: | Cutter Suction Dredger | Power Type: | Diesel |
Dredging Depth: | 10 m | Draught: | 80 cm | Place of Origin: | Henan, China |
Brand Name: | Zoonyee | Model Number: | CSD-200 | Dimension(L*W*H): | 21m*4.6m*1.6m |
Weight: | 60t | Certification: | CE,ISO | Warranty: | 15 months |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
cutter suction dredger*in stock
*CE certificated
*fast delivery
*long warranty time
China hot sale cutter ship
specification:
Items | Specs | Remarks |
Total Length | 21.m |
|
Body Length | 14.0m |
|
Hull depth | 1.6m |
|
Hull width | 4.6m |
|
Main Power | 300KW WeiChai Diesel Model,6160, | Pump Power |
Auxiliary Power | 24KW |
|
Pump model | WN200 Suction10" Discharge8" | Shijiazhuang |
Suction Pump Dia | 250mm |
|
Discharge Pump Dia | 200mm |
|
Water flow | 800-1000m³/h(Capacity-min 100M3) |
|
Discharge Distance | 1500m (Maximum ) |
|
Total max weight when working | 40T |
|
Spuds | 325mm Two sets (Hydraulic) | 12 metre |
Winches | 2 Sets for horizontal movement, one for ladder |
|
Cylinder | Two Hydraulic Cylinders |
|
Operation System | PLC Hydraulic System |
|
Operating Cabin | With air condition. All the operating system with English description. |
|
Dredging depth | 1-9m |
|
|
|
|
|
|
|
Spray-paint | 3 layers,Anti rust guarantee 1 year |
Photos:
