(Manufactory) Free Sample Gps Tracker External Antenna
US$ 2 - 5
MOQ: 10 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
jinchang
Model Number:
JCA001
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
(Manufactory) Free Sample High Quality Low Price Gsm External Antenna With Sma ConnectorUS$ 0.8 - 3MOQ: 20 Pieces -
(Manufactory) Free Sample High Quality Gps/gsm Shark Fin Car AntennaUS$ 3.5 - 7.5MOQ: 20 Pieces
-
(Manufactory) Internal Antenna Used in GsmUS$ 0.5 - 2MOQ: 100 Pieces
-
(Manufactory) Free Sample High Quality Dual Band Gsm Internal AntennaUS$ 0.7 - 2MOQ: 50 Pieces
-
(Manufactory)Free Sample High Gain Flexible 433mhz AntennaUS$ 0.5 - 2.5MOQ: 100 Pieces
Place of Origin
Zhejiang, China
Brand Name
jinchang
Model Number
JCA001
Car Make
all
Frequence Range
1575mhz
Gain(dB)
28
Cable Length
all
gps tracker external antenna
Electrical Characteristics
1.1 Dielectric Antenna
Form 1
No. |
Item |
Specifications |
Post Environmental Tolerance |
1 |
Center Frequency(MHz) |
1575.42 MHz |
±1MHz |
2 |
Band Width(MHz) |
±5 MHz |
±1 MHz |
3 |
V.S.W.R(in BW) |
<1.5 |
— |
4 |
Gain(Zenith) |
3 dB |
±0.5 dB |
5 |
Polarization |
RHCP |
— |
6 |
Impedance |
50 Ω |
— |
1.2 LNA/Filter
Form 2
No. |
Item |
Specifications |
Post Environmental Tolerance |
1 |
LNA Gain |
28±2 dB |
±2.5 dB |
2 |
Noise Figure |
<1 |
— |
3 |
Filter Insertion Loss |
<3db |
-- |
4 |
Ex-band Attenuation |
35dB@CF±50MHz/50dB@CF±100MHz |
|
5 |
Supply Voltage |
2.2~5V DC |
|
1.3 Mechanical
Form 3
No. |
Item |
Specification |
1 |
Cable |
RG174 3m/5m or others |
2 |
Connector |
SMA/MMCX/FAKRA or others |
3 |
Plastic Housing |
Black |
4 |
Mounting |
Magnet/Adhesive |
