Gps+gsm+fm Shark Fin Antenna

Gps+gsm+fm Shark Fin Antenna thumbnail-1
Gps+gsm+fm Shark Fin Antenna photo-1
US$ 2 - 3 MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
JIASHANJINCHANG
Model Number:
JCM070
Contact Supplier Request Quote Chat Now
Jiaxing Jinchang Electron Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name JIASHANJINCHANG
Model Number JCM070
Car Make Combination Antenna
Frequence Range Combination Antenna
Gain(dB) 3±0.5dBi
Cable Length Combination Antenna

Specifications

Shark fin antenna
SIZE: 91*62*62mm
Gain: 3dBi

gps+gsm+fm shark fin antenna



1.  Combination Antenna

2. Model: JCM070



3        Electrical Characteristics

3.1 Dielectric Antenna

Form 1

No.

Item

Specifications

Post Environmental Tolerance

1

Center Frequency

1575.42 MHz

±3 MHz

2

Band Width

±5 MHz

±1 MHz

3

V.S.W.R(in BW)

1.5:1

—

4

Gain(Zenith)

3 dB

±0.5 dB

5

Polarization

RHCP

—

6

Impedance

50 Ω

—



3.2 LNA/Filter

Form 2

No.

Item

Specifications

Post Environmental Tolerance

1

LNA Gain

28±2 dB

±2.5 dB

2

Noise Figure

1.5 dB

—

3

Filter Out Band Attenuation

12dB  Min  f0+50MHz

16dB  Min  f0-50MHz

±1.0 dB

4

DC Voltage

2.2~5 V

5

DC Current

5~15 mA



3.3   GSM Antenna

Form 3

No.

Item

Specifications

1

Frequency

824~960 MHz/1710~1990 MHz

2

V.S.W.R(5m)

≤2.0:1

3

Gain(Zenith)

2 dBi

4

Impedance

50 Ω



3.4 FM Antenna

Form 4

No.

Item

Specifications

1

Frequency

525~1605 kHz / 88~108 MHz

2

V.S.W.R(5m)

≤2.0:1

3

Gain(Zenith)

20 / 12 dBi

4

Impedance

50 Ω













3.5   Mechanical

Form 5

No.

Item

Specification

1

Cable

RG174 3m/5m or others

2

Connector

SMA/SMB/MCX or others

3

Plastic Housing

Black

4

Mounting

Screw



gps+gsm+fm shark fin antennagps+gsm+fm shark fin antenna
