HS1177 Sony 600TVL CCD Mini FPV Camera 2.8mm Lens Special for QAV250 Quadcopter

HS1177 Sony 600TVL CCD Mini FPV Camera 2.8mm Lens Special for QAV250 Quadcopter thumbnail-1
HS1177 Sony 600TVL CCD Mini FPV Camera 2.8mm Lens Special for QAV250 Quadcopter thumbnail-2
HS1177 Sony 600TVL CCD Mini FPV Camera 2.8mm Lens Special for QAV250 Quadcopter thumbnail-3
HS1177 Sony 600TVL CCD Mini FPV Camera 2.8mm Lens Special for QAV250 Quadcopter thumbnail-4
HS1177 Sony 600TVL CCD Mini FPV Camera 2.8mm Lens Special for QAV250 Quadcopter thumbnail-5
HS1177 Sony 600TVL CCD Mini FPV Camera 2.8mm Lens Special for QAV250 Quadcopter photo-1
HS1177 Sony 600TVL CCD Mini FPV Camera 2.8mm Lens Special for QAV250 Quadcopter photo-2
HS1177 Sony 600TVL CCD Mini FPV Camera 2.8mm Lens Special for QAV250 Quadcopter photo-3
HS1177 Sony 600TVL CCD Mini FPV Camera 2.8mm Lens Special for QAV250 Quadcopter photo-4
HS1177 Sony 600TVL CCD Mini FPV Camera 2.8mm Lens Special for QAV250 Quadcopter photo-5
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Type:
Airplane
Power:
Battery
Radio Control Style:
RC Hobby
Contact Supplier Request Quote Chat Now
Shenzhen Bater Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Airplane
Power Battery
Radio Control Style RC Hobby
Place of Origin Guangdong, China
Brand Name SONY
Model Number HS1177

HS1177 Sony 600TVL CCD  Mini FPV Camera 2.8mm Lens Special for QAV280 Quadcopter

Product Description

 HS1177 Sony 600TVL CCD  Mini FPV Camera 2.8mm Lens Special for QAV280 Quadcopter

Features:

  • 1/3" SONY SUPER HAD II CCD
  • 600TVL, high picture quality
  • Aerodynamic plastic case (12g with case)
  • Low RF interference
  • IR Blocker
  • FPV friendly cable with JR connector
  • Nextchip 2040 DSP
  • Powerful OSD menu
  • D-WDR (Wide Dynamic Range)
  • 2D-DNR (Digital Noise Reduction)
  • Low Power Consumption(70mA)
  • Mirror function
  • Low illumination: 0.01Lux

  • Specifications:

    • CCD: 1/3” Sony SUPER HAD II CCD
    • Pixel PAL: 976(H) x 494(V)
    • NTSC: 768(H)×494(V)
    • TV System: PAL/NTSC(according to country)
    • Resolution : 650TVL(b/w), 600tvl(color)
    • Synchronization: internal synchronize
    • Shutter Speed (CCD IRIS) PAL: 1/50~1/100000 sec; NTSC: 1/60~1/100000 sec
    • Noise: > 60 (AGC OFF)
    • Video Out : 75ohm, synchronize
    • Min. Illumination: 0.01Lux
    • Auto Gain: Off/Low/Mid/High
    • Back Light Compensation (BLC): Off /Back light compensation/ Strong light suppression
    • Private shading (PRIVACY): 1~8 private shading area
    • Motion Detection (MD): On/ Off (Multi level sensitivity settable)
    • Auto White Balance: Manual / Auto / Auto track
    • Mirror : Horizontal Mirror optional
    • Negative : Positive / Negative optional
    • Color to B&W: Auto
    • DNR : 2DNR
    • WDR: D-WDR
    • Day / Night Shift : Auto/ Color/ B&W
    • Menu (OSD): English menu
    • White Dot Repair: Support
    • Image Adjustment: Support
    • Camera Title : Support
    • Power Requirement : DC5V~17V
    • Working Temperature : -10 C ~ +50 C
    • Working Humidity : 20~80%
    • Storage Temperature : -40 C ~ +60 C
    • Storage Humidity : 20~95%
    • Dimensions(mm) : 25X25(W*L)
    • Power Consumption: 70mA
