High Power LED PCB Module 10W for Signage
SLT LED Light Strips are a comprehensive application of LED optoelectronic light source that is both energy efficient and decorative allowing us to create an ambient setting or environment with a special feature atmosphere. They are ideal for discrete lighting, and edge lighting for light boxes. The whole design has the merits of beautiful modeling, compact structure and delicate appearance. It can be a direct replacement for lamps that you use at this moment in time. Extremely bright, high Ra-color rendering index, it's the latest indoor illumination product. No need to use ballast and starter, and no flicker, with an estimated lifespan of more than 50,000 hours.
Features:
High Luminous Efficiency
We use top-quality LED chips for this Light Strip. In structural design, a unique optical lens technology ensures non-point source and soft light.
Great lighting source
The LED is of high quality, which is from American. It can resist higher ESD, UV, and IR. It is encapsulated with low a lumen decay process so it will last longer.
Quality of light
SLT adopts constant-voltage output power to fully guarantee the long life span and stable performance of the products. By using the excellent LEDs with wonderful color rendering index, high lumen maintain rate, and no-flicker trait, our products give you a brighter, more attractive, and harmonious atmosphere.
Fantastic Design
The round lenses on the top emit light more evenly and aluminum base on the bottom comes along with good cooling. Easy to install is due to the flat surface. SLT lighting have different view angle that distributes light across a larger surface area and is over 3 times brighter than conventional fluorescent bulb or cabinet lamp.
Environmentally responsible
This environmentally responsible LED system complies with RoHS, CE and UL standards. SLT lighting contains no lead, mercury or glass, so handling and disposal are less of a concern. What is more, it has a higher efficiency than previous lights, effectively delivering more lumens per watt.
Convenient installation
Running without ballast and starter, connect male and female connector directly.
1. LED qty: 3led /5led/9led/15led/18led, with different length
2. LED Brand: Epistar / Cree/ Osram / Samsung, customized
3. Angle: 9*50° / 15*60°/20*60°/10*45°/10*40°/30°. customized
4. Terminal:3P/2P/DC, customized
5. Color temperature: warm white(3000-3500K), natural white(4000-5000K) and cool white(6000-7000K), most customer do cool white. RGB and RGBW ( RGB+White)
Application:
Why clients choose us?
1. Good quality
2. Resonable price
3. Safety packaging
4. Short lead time
5. One-Stop service
Specification:
| Code | SL-BL005-100 |
| Voltage | DC24V |
| Power | 10W |
| Lumen | 850-950lm |
| C.T | 6000-7000K |
| led | Cree |
| Size |
360*23*16mm or 300*23*16mm |
| Certificate | UL ETL, CE |
| Warranty |
2 years |
Quality control:
1. Before producing, we would strictly check the material, color, wick,etc.
2. Aging for every light about 12-24hours
3. Our salesman would trace every phase of production from the beginning.
4. We have a QC team, every piece product sould be inspected before packing.
Other options:
Fujian Sunlighte Optoelectronics Technology Co.,Ltd. established in 2004, strong in business of Advertising Lights, including trade show light and advertising backlight, such as pop up light, roll up light, led strip light and led backlight.
We have been in this line moe than 10 years Our products have been exported to USA, Europe, Australia, South Affrica, etc.
Based on our experience,our reasonable price, high quality and considerate service. Our products enjoy high reputation in our domestic and oversea market.
SLT's Products Qualifications
UL, ETL, CE, and compliance with RoHS standard.
SLT's High Efficiency Sales Team
With a sales team of 12 members in total,4 of them have being over 5 years experience in international trade, even two of them have being over 10 years experience regarded, all of them do familiar with international practice.
SLT's Location
Locates in a beautiful seaside garden city of Xiamen, China. Which is one of the most important international traffic hubs in Southeast of China, it's only three hours express train from HongKong.It takes about 5 minutes from our factory to Xiamen Airport by car.
Thanks a lot for taking your time and learning more on SLT company, and our products. You are warm welcome to contact us in time if you have any other further inquiries, we look forward to establish long-term cooperation relationship with you.
1. What the depth of the light box should be if we want to install the LED
module in it?
For single side light box the depth should be at least 80mm(the distance from the center of the lens to the fabric should be at least 70mm), for the double sides light box, the depth should be more than 120mm(the distance from the center of the lens to the fabric should be at least 60mm).
2. Are the LED modules difficult to assemble?
Not at all. You can install the LED module in the light box with limited skills in a matter of minutes.
3. Do I need an electrician to install the LED modules and power suppliers?
If you have, that is better, but if there is no elctrician, that is also no problem.. By redesigning all parts with the plug-and-pluy principle, anyone can install the LED modules and power supplies.
4. How many LED module should be installed in a 1 square meter light box?
4pcs 10W 5 LED module is enough, if you need very bright light effect, you can install 8pcs 10W 5 LED module in the light box.
5. What is the weight of the LED modules?
The 9 LED Module is 125g/pc., 100pcs/CTN, 15kg/CTN; 5 led module weight 100g/pc, 50pcs/CTN, 5kg/CTN
6. What kind of LED is used in the LED module?
Normally CREE, Epistar, Osram, Samsung. Or can be customized.
7. What is the power consumption of a 1 square meter light box if it is installed 5pcs 10W LED module?
One LED module power is 10W, so if you install 4pcs in the 1square meter light box, the power consumption is 40W. If you install 8pcs in the 1 square meter light box, the power consumption is 80W.
8. How many amperes does it need?
One 10W 5pcs power LED module needs 0.42A, one 7W 3pcs 5pcs power LED module needs 0.292A, one 12W 9pcs power LED module needs 0.5A. But the amperes of the power supply should be 20% higher than the amperes of the LED modules.
9. Can the LED module be used without the aluminum profile?
No. we suggest installed on Aluminum profile for better heat sink. The lifespan of LED modules will be longer.
10. How many LED modules can I connect most in series?
The 5pcs 10W LED module suggest connect Max. 5pcs in one group, the 3pcs 7W LED module suggest connect Max. 7pcs in one group, the 9pcs 12W LED module suggest connect Max. 5pcs in one group, 6pcs 24W RGB led module suggest connect Max. 4pcs in one group.
