Negotiable MOQ: 10 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Light Source:
LED
Input Voltage(V):
DC24V
Lamp Power(W):
8
Contact Supplier Request Quote Chat Now
Fujian Sunlighte Optoelectronics Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Xiamen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Light Source LED
Input Voltage(V) DC24V
Lamp Power(W) 8
Lamp Luminous Flux(lm) 650
Lamp Luminous Efficiency(lm/w) 80
Color Temperature(CCT) Other, 3000-7000
Working Temperature(℃) -20, +60
Working Lifetime(Hour) 20000
IP Rating Other, IP40
Certification CE, EMC, ETL, FCC, GS, LVD, PSE, REACH, SAA, UL
Emitting Color Other, warm white/cold white
Lamp Body Material Aluminum
Place of Origin Fujian, China
Brand Name SLT
Model Number SL-BL007

Cheap Super thin brightness Competitive price CE Cetificated 300 led panel LED Trade show light,dimmable led tile,led module supplier for Advertising light box 1. High power CE Cetificated LED Trade show light Specification for exhibition Cheap super thin brightness Competitive price CE Cetificated 300 led panel LED Trade show light,dimmable



Cheap super thin brightness Competitive price CE Cetificated 300 led panel LED Trade show light,dimmableCheap super thin brightness Competitive price CE Cetificated 300 led panel LED Trade show light,dimmableCheap super thin brightness Competitive price CE Cetificated 300 led panel LED Trade show light,dimmableCheap super thin brightness Competitive price CE Cetificated 300 led panel LED Trade show light,dimmableCheap super thin brightness Competitive price CE Cetificated 300 led panel LED Trade show light,dimmableCheap super thin brightness Competitive price CE Cetificated 300 led panel LED Trade show light,dimmable





 Cheap High brightness CE Cetificated LED Trade show light Details for exhibition Cheap super thin brightness Competitive price CE Cetificated 300 led panel LED Trade show light,dimmable





Cheap super thin brightness Competitive price CE Cetificated 300 led panel LED Trade show light,dimmable





(1)Cheap Super thin   High brightness CE Cetificated LED Trade show light Standard Accessories for exhibition flat head screw:8PCS



Screw:4PCS



E-connector:4PCS



Insulation pad:4PCS



Cheap super thin brightness Competitive price CE Cetificated 300 led panel LED Trade show light,dimmable



(2)Cheap  High brightness CE Cetificated LED Trade show light Optional Accessories for Aluminum profile IR CONTROLLER



Cheap super thin brightness Competitive price CE Cetificated 300 led panel LED Trade show light,dimmable



Cheap High brightness CE Cetificated LED Trade show light Adaptor for exhibition :



Cheap super thin brightness Competitive price CE Cetificated 300 led panel LED Trade show light,dimmable









Cheap High brightness CE Cetificated  LED Trade show light Connection without dimmer for exhibition :



Cheap super thin brightness Competitive price CE Cetificated 300 led panel LED Trade show light,dimmable





Cheap High brightness LED Trade show light Installation for exhibition :



1.Non-mechanical extrusion on the LED light board and its components,



2. Protect the PCB light board during installation.



3.,Meet the requirements and safety standards of electronic components before installing LED light board (in the case of live work), don’t live operation, prevent short circuits.



4. It can be directly input DC/AC24V power. If it is installed with dimming remote, entering a remote control input terminal of the power supply output DC24V, again from the remote control output terminal connected to the circuit board, as shown above single dimming connection, and then its dimmable function works.



5. When install a large area, the PCB board should be put in the same direction, so that the PCB board positive +to positive +, negative -to negative -. After fixing with screw lock E-type gaskets connection, maximum connection 10 pcs with one power.



6. Each piece of the input voltage is DC24V, the input voltage can not be used directly with AC220V. 30x30cm per sheet lamp, the board power is 8W, Noted that the input voltage DC24V + corresponding to the lamp panel +, the input voltage of the the DC24V-corresponding lamp panel - , not allowed reversed connection.



7. Maximum power supply. 150W 24V switching power can supply up to 18pcs 30X30CM light board (8W).





4.Cheap High brightness CE Cetificated LED Trade show light Features  for exhibition

Model

Size/mm

LED Q’ty

Luminous flux

Input voltage

Total Power

SL-BL007-A080

300*300*10

96

600LM

DC/AC24V

8W

SL-BL007-B020

75*300*10

24

150LM

DC/AC24V

2W

SL-BL007-C020

75*300*10

24

150LM

DC/AC24V

2W

SL-BL007-D020

300*75*10

24

150LM

DC/AC24V

2W

SL-BL007-E006

75*75*10

6

40LM

DC/AC24V

0.6W

SL-BL007-F006

75*75*10

6

40LM

DC/AC24V

0.6W







Cheap High brightness CE Cetificated Specification of each Adjustable LED Trade show light chip for exhibition :

NO.

Item

Units

Parameter range

1

limited voltage

V

DC3-3.4V

2

LED current LED

mA

20mA

3

Emitting Angle

°

120°

4

Wavelengthλd(nm)Or Tc(k)

K

5500-8000K

5

luminous flux

LM

7-8LM

6

working environment

°C

-20~~+50

7

storage condition

°C

-30~~+70





5. Cheap High brightness CE Cetificated Adjustable LED Trade show light Use manual for exhibition



Please read the specification first to make sure the using condition is fit.

Please shut off the switch before connecting the product.

OUTPUT:DC24V/AC24V

Indoor use only.


Packaging & Shipping







Competitive price LED backlight Package for Aluminum profile :



High power






Our Services





Cheap High brightness CE Cetificated LED Trade show light Application for exhibition :
