YS-LXZK-480 Full Auto Continous Stretch Vacuum

YS-LXZK-480 Full Auto Continous Stretch Vacuum photo-1
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Apparel, Beverage, Chemical, Commodity, Food, Other, Medical, Textiles, Apparel, Beverage, Chemical, Commodity, Food, Machinery & Hardware, Medical, Textiles
Packaging Type:
Bags, Barrel, Belt, Bottles, Cans, Capsule, Film, Foil, Pouch
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Apparel, Beverage, Chemical, Commodity, Food, Other, Medical, Textiles, Apparel, Beverage, Chemical, Commodity, Food, Machinery & Hardware, Medical, Textiles
Packaging Type Bags, Barrel, Belt, Bottles, Cans, Capsule, Film, Foil, Pouch
Packaging Material Plastic
Automatic Grade Semi-Automatic
Driven Type Electric

Specifications

Length
3630mm
Width
900mm
Height
1775mm
Loading area
1000-2000mm
Upper film width
390mm
Lower film width
420mm
Max forming depth
60mm
Lower film reel diameter
400mm
Upper film reel diameter
300mm
Reel core diameter
76mm
Maximum pitch
350mm
Max pitch with pre-heating station
350mm
Working efficiency
3-7cycles/min
Total power
12KW
Main motor power
1.5KW
Heating total power
6KW
Installed power (pump excluded)
8KW
Compressed air pressure
0.6-0.8MPa
Compressed air consumption
1m3/min
Water consumption
90L/h
Power supply
380V, 50HZ, 3PH
Vacuum pump
Germany BUSCH, 100m3/h
Main electrical equipments
Germany SIMENS, France Schneider
Weight
1600kg
Options
1
Color film cursor location system
2
Automatic coding, ink-jet printing system
3
Mould cooling system
4
Outfeed conveyor belt
5
Modified atmosphere packaging(MAP) sem


Application scope: Suitable for foods, bean products, meat products, seafood, fruits, vegetables, pickles, medicine products and metal components vacuum packaging
