5V/12V/15V24V/60W Switch Mode Power Supply

5V/12V/15V24V/60W Switch Mode Power Supply thumbnail-1
5V/12V/15V24V/60W Switch Mode Power Supply photo-1
US$ 6 - 6.5 MOQ: 5 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
SCOTT
Model Number:
SC-60W-M
Contact Supplier Request Quote Chat Now
Shenzhen Scott Electronics & Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name SCOTT
Model Number SC-60W-M
Output Power Other, 60w
Output Type Single
Input Voltage Other, AC85-265V
Output Voltage 5V12V15V24V
Output Current 0-12A

Specifications

5V/12V/15V24V/60W switch mode power supply
1. CE,ROHS approved
2. UL APPROVED FOR HIGHER PRICE

5V/12V/15V24V/60W switch mode power supply
CE, ROHS, UL CERTIFICATE
size: 129*98*38mm or 111*78*36mm

Model S-60-5 S-60-12 S-60-15 S-60-24
Specification
DC output voltage
5V
12V
15V
24V
Output voltage error(Note2)
±2%
±1%
±1%
±1%
Rated output current
12A
5A
4A
2.5A
Output current rage
0-12A
0-5A
0-4A
0-2.5A
Wave and noise(Note 3)
120mVp-p
120mVp-p
150mVp-p
150mVp-p
Inlet stability(Note 4)
±0.5%
±0.5%
±0.5%
±0.5%
Load stablity (Note 5)
±1%
±0.5%
±0.5%
±0.5%
DC output power
60W
60W
60W
40W
Efficiency
72%
76%
77%
79%
Adjustable range for DC voltage
+10,-5%
+10%
+10%
+10%
AC input voltage range 90~132VAC/180-264VAC selected by switch 47-63Hz;120-370VDC
Input current 2A/115V 60A/230V
AC INnrush current

Cold-start current 30A/115V 60A/230V
Leakage current <3.5mA/240VAC
Overload proctection 105%~150% Tpye:pulsing hiccp shutdown Reset:auto recovery
Over-voltage protection 115%~135%
High-temperature protection
Temperature coefficient ±0.03%/°C(0~50%)
Setup rise hold up time 800ms,50ms,10ms/115V 300ms,50ms,80ms/230VAC
Vibration 10-500HZ,2G 10min,/1cycle,Period for 60min,Each axes
Withstand voltage Input and output internal;1.5KVAC,Input and enclosure;1.5KVAC,Output and enclosure;0.5KVAC
Isolation resistance Input and output internal:Input and enclosure,Output and enclosure;500VDC/100MΩ
Working temperature and humidity -10°C~+60°C(Refer to output derating curve),20%~90%RH
Store temperature and humidity -20°C~+85°C,10%~95%RH
Overall dimension 159×97×38mm
Weight 0.55Kgs
Safety standards UL1012 TUV EN6050(IEC,UL1950)Approved
EMC standards CISPR22(EN55022),IEC801-2,3,4,IEC555-2 Verification
Note;
1.The testing condition for the paramenter above is :230VAC input,rated load,25°C70% RH.Humidity.
2.Error.include the setting error,line stability and load stability.(Note:5).
3.Wave test:adopting "A12"double wire for 20MHz,and 0.1UF&47UF capacitor short-circuit for interrupting.
4.Inlet voltage stability test:when is over load,the lowest voltage of inlet is up to the highest voltage.
5.Load stability test:the load is from 0% to 100%.
