Help CenterPP Spun Filter
Related Products
Specifications
1.PP spun filter used in water purify2.various micron and length
3.we are manufactor of the machine
4.both machine and filte
The PP Melt Blown Filter Cartridge production line
The production line includes the following equipments:
First part: |
Air compressor (alternate using) |
2 sets 15KW/set |
OR screw compressor(without a break) |
1 set 18.5KW |
|
Second part |
Air tank |
1 set the volume is 0.4 M3 ----------------------- (no electrical) |
Third part: |
Heating machine |
1 set 18KW |
Forth part |
SJ-45 single screw extruder |
2 sets (total power is 31KW) |
extruder power is 5.5KW/set (changing frequency control speed) | ||
Motor in the part of heating is 10KW/set | ||
Fifth part |
Mould |
2 sets (no electrical) |
Sixth part |
Takein machine |
1 set 3kw |
Seventh part |
Cutting machine |
1 set (no electrical) |
Eighth part |
Controller |
2 sets(big one and a small one) ----------------- (no electrical) |
Ninth part |
Cleaning box for the mould |
2kw 1 set (the cleaning box is used for the moulds on the extruder, the holes on the mould might be blocked by pp material) |
Tenth part(pay in addition) |
Automatic feeding machine |
2 sets |
Our engineer has researched a new equipment that could make the face of filter cartridge more smooth. | ||
The parameter of the production line(best energy-saving):
The rated power: 67KW (for the first kind of production line)
The rated power: 70.5KW (for the second production line)
The actual power: 35KW (Power Consume is 35kwh per hour )
Raw material: Polypropylene
Speed of machine:0-1400 r/min
Filter precision:1-100 microns
Machine weight: 3.8 tons
Production capacity:3000-4000pcs/day
On the basis of 10'' length,,OD=60mm
The machine could make 10'',20'',30'',40'' and other length as whatever you want.
There are four important features for our machine as followed:
first: it saves more electrical than others pp machines.
you know, our rated power: is 70KW and actual power is 35kw when machine is working,but the power of many machines from other factor-y is very high ,which can reach 100KW , as per the situation in the field, our machine is the best choice for you.
second: its output is very large
we also visit many plastic factory, their out is average 2000 pcs/day at most, but ours can reach 2200 pcs/day at least in summer, our output can reach 3200 pcs/per day.
Third: we use variable frequency motor.
Fourth: It has features of high efficiency and energy saving, high power factor and high reliability
pp melt blown filter cartridge
1) High precision, high flow rate, high pressure resistance and high corrosion resistance.
2) Consistent particle retention and superior contaminants holding capacity With longer filtration life.
3) No fiber releasing and media migration
4) No surfactants or adhesives are present to interrupt product quality or Cause foaming.
5) Board chemical compatibility for variety of applications
6) Internal diameter: 28/ 32 mm.
7) External diameter: 58-114 mm
8) Length: 10", 20", 30", 40" and other length as whatever you want.
9)Applicable PH value:1-1310
10)Precision of filtering(micron):1,3,5,10,20,30,40,50...
Operation conditions:
1). Max operating temperature: 70°C
2) Materials: 100% polypropylene
3) Interface of filter cartridge: flat
4) Max differential pressure: Positive 0.4Mpa
Filter precision (μ m) |
1 |
3 |
5 |
10 |
20 |
30 |
50 |
outside precision (μ m) |
10-15 |
15-25 |
25-35 |
30-40 |
35-50 |
40-60 |
60-90 |
Max particle (μ m) |
15 |
25 |
35 |
40 |
50 |
60 |
90 |
Flow (L/min) |
10 |
14 |
17 |
20 |
24 |
28 |
32 |
Applicable fields:
- Electronic, power Industries: Pure Water, Gas, Electroplating Liquid, Presswork etc
- Chemical & petrochemical Industries: Solvent, Paint, Magnetism paint, Detergent, Liquid wax etc
- Medicine & Pharmaceutical: Hospital Water, Injection and Oral Liquid
- Food Industry: Food, Drink, Drinking Water, Alcohol etc.
