Product Details
Place of Origin: | Guangdong, China | Brand Name: | SCOTT | Model Number: | SC-T-1000S |
Type: | Manual Switch | Voltage: | Other, 5V-24V |
Product Description
T-1000S SD card 2048 pixels led pixel controller / rgb led controller
Support chips:
Support IC type | Module in LedEdit software | Pixel numbers | Remark |
LPD6803,D705,1101,6909, 6912 | T-1000S-6803 | 2048 pixel
|
|
LPD8806,LPD8809 | T-1000S-8806 | 2048 pixel |
|
TM1803,TM1804,TM1809,TM1812 | T-1000S-TM | 2048 pixel | TM1804 and TM1809 low speed and high speed |
TM1903TM1904TM1909TM1912 | T-1000S-TM19 | 2048 pixel |
|
UCS6909UCS6912UCS7009UCS5903 | T-1000S-UCS-32 | 2048 pixel |
|
UCS1903UCS1909UCS1912 | T-1000S-UCS-256 | 2048 pixel | low speed and high speed |
UCS3903 | T-1000S-UCS-1024 | 2048 pixel |
|
DMX512 | T-1000S-DMX | 170/512 pixel | Compatible DMX512 |
WS2801,WS2803 | T-1000S-WS | 2048 pixel |
|
WS2811 | T-1000S-WS2811 | 2048 pixel | low speed and high speed |
DS189 | T-1000S-DS189 | 2048 pixel |
|
TLS3001,TLS3002TLS3008 | T-1000S-TLS | * pixel |
|
P9813 | T-1000S-P9813 | 2048 pixel |
|
SM16715 | T-1000S-SM16715 | 2048 pixel | low speed and high speed |
SM16716 | T-1000S-SM16716 | 2048 pixel |
|
BS0901,BS0902 | T-1000S-0901 | 2048 pixel |
|
BS0815 | T-1000S-0815 | 2048 pixel |
|
Connection diagram:
7.5V-24V | DC power input, to provide two sets of power input, select a group can be. |
5V | Power Ground. |
GND | Error indicator |
ERROR | Power LED |
POWER | SD card slot |
SD CARD | Output CLK |
CLK | Output DATA |
DAT | Signal Ground |
GND |
|
|
|
GND | Signal Ground |
