High Tensile Hydraulic Hose Brass Coated Steel Wire
US$ 1,250 - 1,350
MOQ: 20 Tons
Key Specifications
Get Latest Price
Steel Grade:
steel
Wire Gauge:
0.35mm
Place of Origin:
Henan, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao/Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High Tensile Brass Plated Steel Wire for Industrial HoseUS$ 1,250 - 1,350MOQ: 20 Tons -
High Tensile Brass Plated Steel Wire Export to IndiaUS$ 1,250 - 1,350MOQ: 20 Tons
-
0.30mm Brass Coated Steel Wire for Hydraulic Hose Reinforcement FactoryUS$ 1,000 - 2,000MOQ: 10 Tons
-
Brass Plated Wire for Hydraulic HoseNegotiableMOQ: 20 Tons
-
Brass Coated Wire for Hydraulic HoseNegotiableMOQ: 20 Tons
Steel Grade
steel
Wire Gauge
0.35mm
Place of Origin
Henan, China
Type
Copper Coated
Application
Other, Netting, Hydraulic hose, high pressure hose,rubber hose
Alloy Or Not
Non-alloy
Special Use
Cold Heading Steel
Model Number
0.35mm
Brand Name
Hengxing
Specifications
rubber hose reinforcement steel wire1. Output is 5,000 tons per month
2. China public listed group factory over 3000 employee
Brass coated hose reinforcement steel wire factory
Description:
The high-pressure hose wire is a kind of steel wire products of high strength, whose surface is plated with a uniform layer of brass alloy. It is used for the reinforcement of the rubber tube by the way of weaving or winding, and is mainly applied in the hydraulic oil tube. The high-pressure rubber tubes can resist high temperature, high pressure, high impact according to different applications, and can be applied in specific occasions such as machinery, aviation, automotive, marine, oil drilling and so on.
Advantages:
Hengxing is specialized in developing and producing high-pressure hose wires, which have various specifications and long service life, and resist high temperature, high pressure and high impact. It has an excellent performance is all aspects.
Nominal diameter |
Tolerance |
Tensile strength |
Torsions (L=100xø) |
Reverse bends (r=2.5mm) |
mm |
mm |
(Mpa,N/mm2) |
Min |
Min |
|
0.2
|
±0.010 |
2150~2450 |
70 |
125 |
2450~2750 |
70 |
|||
2750~3050 |
65 |
|||
3050~3350 |
60 |
|||
|
0.25
|
±0.010
|
2150~2450 |
70 |
125 |
2450~2750 |
70 |
125 |
||
2750~3050 |
65 |
105 |
||
3050~3350 |
60 |
75 |
||
|
0.3
|
±0.010 |
2150~2450 |
65 |
105 |
2450~2750 |
60 |
95 |
||
2750~3050 |
60 |
85 |
||
3050~3350 |
50 |
60 |
||
|
0.35
|
±0.015 |
2150~2450 |
65 |
60 |
2450~2750 |
60 |
60 |
||
2750~3050 |
60 |
55 |
||
3050~3350 |
50 |
50 |
||
|
0.4
|
±0.015 |
2150~2750 |
60 |
55 |
2450~2750 |
60 |
55 |
||
2750~3050 |
60 |
50 |
||
3050~3350 |
50 |
45 |
||
|
0.42
|
±0.015 |
2150 ~2450 |
60 |
50 |
2450 ~ 2750 |
60 |
50 |
||
2750 ~3050 |
50 |
45 |
||
|
0.46
|
±0.015 |
2150~2450 |
60 |
45 |
2450~2750 |
60 |
45 |
||
2750~3050 |
50 |
40 |
||
|
0.5
|
±0.015 |
2150~2450 |
60 |
40 |
2450~2750 |
60 |
35 |
||
2750~3050 |
50 |
30 |
