Most Popular Energy Saving Plywood Machine Hot Press Machine
US$ 18,000 - 40,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Hot Press
Application:
Plywood
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO/LIANYUNGANG
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Hydraulic Hot Press,Hot Press Machine, Plywood Hot Press,Hot Press Machine for PlywoodUS$ 20,000 - 40,000MOQ: 1 Set -
Veneer Dryer/Hot Press Drying Machine For Veneer/Core Veneer Drier In Plywood FactoryUS$ 18,000 - 40,000MOQ: 1 Set
-
Hot Press/Hot Press/Hot Press Machine/Plywood Hot Press/ Plywood Hot Press MachineUS$ 20,000 - 40,000MOQ: 1 Set
-
Hot Press Drying Machine for Veneer/Veneer Drier in Plywood FactoryUS$ 18,000 - 40,000MOQ: 1 Set
-
Good Quality Plywood Hot Press Machine/Plywood Production Line For Birch Plywood/Particle BoardUS$ 20,000 - 40,000MOQ: 1 Set
Condition
New
Type
Hot Press
Application
Plywood
Pressure
600T
Place of Origin
Shandong, China
Brand Name
JINGUAN
Model Number
JG4*8
Voltage
220V/380V/415V
Power(W)
15KW
Dimension(L*W*H)
1400mm*2700mm*52mm
Weight
31.5T
Certification
ISO9001
Warranty
One Year
After-sales Service Provided
Overseas service center available
Product Description
| 1 | Nominal Gross Pressure | 6000 KN |
| 2 | Direction of Feeding Plate | Horizontal ,Vertical |
| 3 | Layer Counting | 10 |
| 4 | Distance between Hot Platens |
100mm |
| 5 | Numbers of Hot Platens | 11 |
| 6 | Dimension of Hot Platens | 1400×2700×52mm |
| 7 | Type of Pipes | Double Inlet and Outlet Pipes |
| 8 | Numbers of Cylinder | 6 |
| 9 | Diameter of Cylinder | Φ220mm(Shanghai) |
| 10 | Stroke of Cylinder | 1000mm |
| 11 | Pressurization | ≤25 Mpa |
| 12 | Empty Closing Time | About 17 S |
| 13 | Low Pressure Pump Flowing | 355L/min×3 |
| 14 | Allowed Pressure | ≤5 Mpa |
| 15 | Power | 15KW×3 |
| 16 | High Pressure Pump Flowing | About 89L/min |
| 17 | Power | 15 KW |
| 18 | Pressure of Unit Plate Blank | 20 Kgf/cm2 |
| 19 | Dimensions of The Board | 1240×2460mm |
| 20 | Machine Weight | About 40000 Kg |
| 21 | Overall Dimensions | 3590×1400×4070mm |
| 22 | Control Method | Automatic Pumping Station |
| 23 | Thickness of Upper And Lower Crossbeams | 900,1000mm |
| 24 | Thickness of Steel Plate | 30,25,16mm |
| 25 | Steel Plate Of Upright Column | 30,16mm |
| 26 | Thickness of Acctive Crossbeam | 400mm |
| 27 | Thickness of Steel Plate | 30,20mm |
Detailed Images
Double inlet and outlet pipes
Fast closing pumping stations
