2015 most popular oil distillation
- 100 Set / Sets per Month
- Qingdao China
- T/T
- Waste Oil Regenerating Equipment for Various Dielectric Oils
- BZ Transformer oil regeneration Equipment
- Transformer OLTC On-load Tap Changer Oil Purifier//separator/Regeneration/Dehydration Machine
- Insulation Oil Regeneration Machine
- On-load Tap Changer Oil Filter Oil Filtration Machine Oil Decanter
- Specilize Model BZ Transformer Oil Regeneration Unit
Product Details
Condition: | New | Flow: | 10T | Working Pressure: | Normal Pressure |
Place of Origin: | Shandong, China | Brand Name: | Xingfu | Model Number: | XFZL--10 |
Usage: | Other, pyrolysis oil | Voltage: | 380V | Power(W): | 36kw |
Dimension(L*W*H): | 6600mm*2500mm*2850mm | Weight: | 30 ton | Certification: | ASME,CE,ISO,SGS |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Technical Principle
Raw oil starts to gasify and distill after heat to reach uniform temperature level in reactor, and after catalyzed in catalyze tower, to extract petrol and diesel gas component separately from hydrocarbon. Then cooled petrol and diesel component in condenser will be made to petrol and diesel distillate. The remainder will be heavy fuel oil.
Equipment Feature
n Oil yield reaches to 90%, conversion rate to 100%.
n Unique heat system by hot air, avoid high temperature heat reactor directly. Equipment Would be safer and longer working life.
n Research and develop catalyst aiming at fuel oil, to make a better performance at catalyst.
n Equipment processing use full automatic submerged arc welding, X-ray flaw detection, to ensure excellent quality.
Technological Process
n Raw oil after dewater process goes into reactor. Heating, gasifying and cooling to get petrol and diesel component.
n After heating and gasifying, Petrol gas expels from top outlet of catalyze tower, and goes into petrol storage tank after cooling through condenser. Then inject petrol into another big storage tank.
n After heating and gasifying, Diesel gas expels from top outlet of catalyze tower, and goes into diesel storage tank after cooling through condenser. Then inject diesel into another big storage tank.
n Distilled diesel after treatment by oil reconcile tank, will becoming fuel oil with high quality.
n A little of flammable gas go through medium tank and into exhaust gas treatment equipment to be processed. And then go through water deal into furnace to burn.
Main Performance Parameter
Item | Type | XFZL--10 | XFZL--20 |
Capacity | 10T | 20T | |
Working temp. | ≤650° | ||
Fuel | Fuel oil, Natural gas, Liquefied gas | ||
Heating way | Circulating hot air heating | ||
Distillation material | Plastic oil, tyre oil, wasted oil and residual oil | ||
Working pressure | Normal pressure | ||
Consumption | 250 kg | 300 kg | |
Size | 6600×2500×2850(mm) | 8600 × 2700 × 3050(mm) | |
Total power | 36 kw | 36 kw | |
Power consumption | 15 kw/h | 20 kw/h | |
Floor space | 19000 mm × 3600 mm | 19000 mm × 4000 mm | |
Highest point of installation | 6000 mm | 6000 mm |
Remark: This parameter is just for reference. Size change caused by design improvement will not inform customers specially. Please refer to documents enclosed with products.
Product Recovery Rate
Petrol: 15-20%
Gas : 70-75%
Flammable gas: 2-5%
Residue: 10-18%
