Help CenterSuper Bright Red LED 2G11 Lamp 22W
Related Products
-
SMD2835 T8 LED Tube With G13/FA8/HO Socket/Rotating SocketUS$ 6 - 30MOQ: 1 Piece -
G13 2835SMD 1200mm t8 Led Tube 4feet 18W Led Tube With CE RoHSUS$ 6 - 30MOQ: 1 Piece
-
SMD2835 T8 LED Tube With Rotating SocketUS$ 6 - 30MOQ: 1 Piece
-
20W/30W/40W/50W/60w Tri-Proof LED Fixture /Tri-Proof Led LampUS$ 1 - 100MOQ: 1 Piece
-
IP65 Aluminum Tri-proof Led Lamp With AC100-240VUS$ 30 - 89MOQ: 1 Piece
SMD2835 2G11 LED Tube
A. Features:
R High Efficiency : 100-120LM/W, efficiency is up to 80%-90%
R High quality light source : Non-UV or IR radiation, no RF interference, no flickering, no humming
R Low power consumption : 1/3-1/2 of traditional energy saving lamp
R Long life span : Standard life span is 50,000 hours on condition that light flux attenuation to 70%
R High quality and durable: The LED lamp is solid light source , the tubes adopt aluminum alloy and PC as the shell. The product is not easy to break
R Wide Voltage Range: AC85V-265V, adopted to most of the world. Even with the industrial voltage
R Environment friendly: No mercury or lead, the junk can be recycled
R Instant ON/OFF: The LED can be switched on and off instantly even at a very high frequency
R Certifications: CE, RoHS
R Warranty: 2 years
B. Parameters
Model |
Watt |
LED (pcs) |
Length (mm) |
Fluminous Flux (lm) |
PF |
Holder |
EN-2G11-40-8W |
8W |
2835smd-40pcs |
227 |
710-780 |
>0.95 |
2G11 |
EN-2G11-60-12W |
12W |
2835smd-60pcs |
322 |
1060-1190 |
>0.95 |
2G11 |
EN-2G11-72-15W |
15W |
2835smd-72pcs |
417 |
1210-1350 |
>0.95 |
2G11 |
EN-2G11-96-18W |
18W |
2835smd-96pcs |
542 |
1620-1720 |
>0.95 |
2G11 |
EN-2G11-110-22W |
22W |
2835smd-110pcs |
542 |
1930-2050 |
>0.95 |
2G11 |
Chip |
Input Voltage |
RA |
Efficiency |
Frequency |
Constant Circuit Error |
Static Power Consumption |
Epistar |
AC85-265V |
>75 |
>85% |
50-60Hz |
<2% |
<0.5W |
Work Temperature |
Storage Temperature |
Open Protection |
Short Circuit Protection |
Noise |
Power Factor |
Lifespan |
-20-65℃ |
0-65℃ |
OK |
OK |
<240mV |
>0.95 |
50,000H |
C. Instructions:
1. Color temperature can be Warm White: 3000k-3500k; Cool White: 6000k-6500k.
2. Beam Angle can be 90 or 120 degree.
3. Shell material is aluminum alloy plus PC(Clear PC, Milky PC)
D. Detailed Size
Our Model |
Watt (W) |
A |
B |
C |
D |
D1 |
Replacement |
EN-2G11-8W |
8 |
201 |
220 |
227 |
38 |
17 |
2G11 18W |
EN-2G11-12W |
12 |
296 |
315 |
322 |
38 |
17 |
2G11 24W |
EN-2G11-15W |
15 |
391 |
410 |
417 |
38 |
17 |
2G11 36W |
EN-2G11-18W |
18 |
516 |
535 |
542 |
38 |
17 |
2G11 40W |
EN-2G11-22W |
22 |
516 |
535 |
542 |
38 |
17 |
2G11 55W |
E. Application
Hospital, School, Officeroom, etc.
