Advantage
Energy saving up to 50% even lighting output.
Wide range of input voltage: AC 100~240V.
Instant start, no flicking, no humming.
New high efficiency constant current driver.
Special circuit design, each group of LEDs work separately, avoiding any problem of lighting
output caused or influenced by single faulty LED.
No RF interference.
LED Panel 600X600 Specifications
| Input voltage | AC 100~240V | ||
| Panel Input voltage | DC 55~70V (700 mA) | ||
| LED Quantity | 700 pcs (3528 chip) | ||
| Power consumption | 41.65W | ||
| color | White | ||
| Warm white | |||
| luminous flux | 3360lm (white) | ||
| 2800lm (warm white) | |||
| color temperature | 4000~7000k(White) | ||
| 2500~4000k(Warm white) | |||
| Life time | >50,000 Hour | ||
| Operating temperature | -20ºC to + 50ºC | ||
| Storage temperature | -30ºC to + 60ºC | ||
| Luminosity | >975 Lux (ter, White) | ||
| >850 Lux (ter, Warm white) | |||
| Weight | 4.16 KGS | ||
| Size | 595X595X10.4 mm | ||
| Certificates | CE & RoHS | ||
| Water proof | IP20 |
Light Distribution Graph
Illumination Intensity Chart
Installation
This product is simple and convenient installation.The client may be more reasonable application of the product to fit the scenic spot.
Picture show
Application
Commercial Lighting, Office Lighting, Warehouse Lighting, Supermarket Lighting etc
