FXBUW4(E-E Series) Suspension Composite Insulator
- NINGBO SHANGHAI WENZHOU
- T/T
You May Like
Product Details
Place of Origin | Zhejiang, China | Brand Name | CHYHC | |
Model Number | FXBUW4(E-E Series) | Type | Insulator | |
Material | Composite Polymer | Application | Low Voltage |
Product Description
FXBUW4(E-E Series) Suspension Composite Insulator
We can make it to ANSI, IEC, BS, DIN and other standards. We have passed the ISO9001 Quality Certification.
We can make products according to ANSI, IEC, BS, DIN AS, JIS standards and also base on customer's specifications and drawings.
We have passed the ISO9001 Quality Certification, and also we possess different types of test reports, which are issued by independent laboratory
Packaging Detail: | carton |
Delivery Detail: | 20-30days |
Basic Data | |||||
Type | Rated voltage (KV) | Rated failing Load (KN) | Section length (mm) | Dry arcing distance (mm) | Minium creepage distance (mm) |
FXBUW4-10/70 | 10 | 70 | 390±15 | 100 | 200 |
FXBUW4-10/100 | 10 | 100 | 430±15 | 190 | 250 |
FXBUW4-24/70 | 24 | 70 | 460±15 | 260 | 700 |
FXBUW4-24/100 | 24 | 100 | 500±15 | 260 | 700 |
FXBUW4-35/70 | 35 | 70 | 650±15 | 450 | 1015 |
FXBUW4-35/100 | 35 | 100 | 680±15 | 450 | 1015 |
Our Principles:
1)Quality first, customer first, safety first
2)Better service, faster delivery
3)Equal and mutual benefit
4)Honesty and profession
Our service:
1.Swift and professional response
2.Patient and trusty
3.Severe quality control system
4.On-time delivery
Our Mission:
Supply quality products with competitive price & excellent service
Zhejiang Yinhe Cable Co., Ltd is a joint stock enterprise integrated in cable production, research & development,and domestic & international trade.
The company has passed ISO9001 2008 quality certification, CCC China Compulsory Certification, National Electrical Product Safety Certification,
State Construction and Project Commitee Recommended Manufacturer of the Transformation of Urban and Rural Powerrid Construction.
What is our payment term ?
Our payment term is usually T/T 30% in advanced , the balance before picking up the goods.
What is the price term ?
We can provide you FOB , C&F , CIF price for you, according to your requirment.
what is the MOQ of the product ?
The MOQ usually is 300 - 1000m , some type of the cable is in stock.
What about the deivery time ?
The delivery time according to your quantity, Usually it is within 30 working days.
