GB Q235qC/Q235qD/Q235qE/ASTM Grade 36[250]/JIS SM400B/C /DIN S235JR(1.0038)/S235J2(1.0117) bridge steel plate
1.Product Basic Information:
Chemical Composition
Material |
S235JR(1.0038) |
||
Chemical Composition |
Mechanical Properties(In Quenched & Tempered State) |
||
C |
≤0.17 |
Tensile strength(MPA) |
400-550 |
Si |
≤0.35 |
Yield strength (MPA) |
≥250 |
Mn |
≤1.4 |
Elongation(δ5/%) |
26 |
Ni |
≤0.03 |
Reduction in Area (ψ/%) |
- |
Cu |
≤0.30 |
Impact (J) |
- |
P |
≤0.030 |
Hardness |
- |
S |
≤0.03 |
||
Cr |
≤0.30 |
||
N |
≤0.012 |
||
Als |
≥0.015 |
||
2.Product Application Areas:
Our products have been used in all kinds of areas, such as aviation,aerospace,navigation,nuclear energy,chemical industry,
electronic information,achine manufacture, petrochemical, automotive,instrument and meter, Communication ,transportation, and medical instruments, etc.
3.Similar steel grade & equivalent steel materials:
USA |
Japanese |
Gemany |
British |
France |
heat treatment |
Chinese |
ASTM&AISI&SAE |
JIS |
EN DIN |
EN BS |
EN NF |
ISO |
GB |
36[250] |
SM400B SM400C |
S235JR(1.0038) S235J2(1.0117) |
HR235B
|
Q235qC Q235qD Q235qE |
||
4.Product Sales Information:
Material |
S235JR(1.0038) bridge steel plate |
Size |
Thickness:20~50mm Width:1000-1500mm Length: 4~6m |
Origin place |
Made In China |
Delivery Condition |
Hot rolled,cold drawn,forged |
Surface require |
Black,grinding,bright,polish |
Heat treatment |
Quenched,Tempered,annealed |
Packing |
seaworthy packing ,wooden case ,carton,woven bag or at client's requires |
Delivery time |
In 10-50 days |
Trade Term |
EXW,FOB,CIF |
Payments |
T/T or L/C at sight |
Port |
China main Port,such as shanghai,Dalian,Shenzhen port. |
MOQ |
1 Ton |
Standard:
| ASTM | USA | Ameirican Society of Mechanical Engineers |
| AISI | USA | Acronym of American Iron and Steel Institute |
| JIS | JP | Japanese Industrial Standards |
| DIN | GER | Deutsches Institut für Normung e.V. |
| UNS | USA | Unified Numbering System |
Product Advantages:
1, the most commonly used steel plate
2, moderate carbon content
3, good comprehensive property
