Help CenterNTS New Designed Marsh Dredging Excavator
Related Products
-
NTS-32 Floating Excavator for SaleUS$ 1 - 300,000MOQ: 1 Unit -
NTS Series Amphibious Excavator for SaleUS$ 80,000 - 300,000MOQ: 1 Unit
-
Marsh Swamp Buggy Amphibious Excavator for SaleUS$ 1 - 300,000MOQ: 1 Unit
-
Hot Sale NTS-21 Marsh Excavator Swamp Buggy Amphibious ExcavatorUS$ 1 - 300,000MOQ: 1 Unit
-
Dredging Amphibious Excavators for Deep Water Area for SaleUS$ 1 - 300,000MOQ: 1 Unit
Marsh Dredging Excavator Goes Where Traditional Excavators Cannot Go
Marsh Excavators, or Amphibious Excavators specifically designed to maneuver and go through swampy areas with soft underfoot terrain where traditional excavators cannot go. It is extremely productive in dredging, erosion control and erosion prevention. It also provides efficiency in waterway, river and pond shoreline construction and can be used for maintenance and clearing of rivers, lakes and other water projects.
The track chain is a two or three rail system. Shoes and cleats are supported by the track chain which provides a unifying pulling force with a superior weight to drive ratio across each track shoe and cleat.
A manual expansion system allows the pontoons to move in and out by one-foot on each side increasing and reducing the overall footprint of the unit. Highly maneuverable, the system is made of high-grade structural tensile plate steel with some steel components made with 100,000 psi steel.
Applications
1, river dredging, waterway dredging
2, water conservancy project, like Lake excavating, lake dredging, reservoir dredging
3, wetland projects, like forest wetland development, wetland park construction and etc.
4, coastal conservancy project, like the coastal beach development, sea salt
5,aquaculture excavating and dredging project,like fish pond dredging, shrimp pond dredging, pond dredging
6,salt mining projects, like the development of Saline Lake, Saline Lake digging
7, iron ore mineral tailings, gold mineral tailings treatment projec
Parameters
Model |
NTS-18 |
NTS-21 |
NTS-26 |
NTS-32 |
NTS-40 |
Weight(kg) |
18000 |
21000 |
26000 |
32000 |
40000 |
Engine |
Cummins B3.3T |
Cummins 4BTA3.9 |
Cummins 6BTA5.9 |
Cummins 6BTA5.9 |
Cummins 6CTAA8.3 |
Engine |
60 |
82 |
133 |
133 |
198 |
Bucket |
0.34 |
0.45 |
0.8 |
1 |
1 |
Chain Qty |
2 |
2 |
2 |
3 |
3 |
Pontoon |
6650*1312*1601 |
7171*1490*1718 |
8083*1508*1718 |
9148*1623*1810 |
9148*1823*1810 |
Max Digging |
9065 |
10825 |
9867 |
10280 |
12000 |
Max Digging |
5873 |
6955 |
5626 |
5840 |
6600 |
Ground |
17.5 |
14 |
15.2 |
14 |
14 |
Working Tools
By a Quick Coupler arrangement, NTS amphibious excavator can change different working tools according to different working conditions.
Shipment
Usually, it needs two 40HQ and one FR to ship one unitMarsh Excavator/ Amphibious Excavator
