Sonostar good quality handheld portable vet ultrasound scanner pig veterinary ultrasound V10(SS-10V )
Feature
·PC based
·Full digital imaging technology
·10 inch LCD screen(SS-10B)
·Silica gel control panel
·Broadband Multi-frequency probes
·512/1024 frame cine loop
·8 segment TGC
·16 step zoom
·140 body marks
·Powerful information management
·Complete application software packages
·1GB permanent storage
·USB ports
·Compatible with laser/inkjet printers
Specification:
-D-Maximum Scanning Depth: 250mm
-Multi-frequency: 5 segment frequencies
-Zoom: 10 ratio, 1.5, 2.0, 2.5, 3.0, 3.5, 4.0, 4.5, 5.0, 5.5, 6.0
-Image gray scale: 256 level gray scale
-Cine Loop:1024 frames
-Scanning mode: B, 2B, B/M, M, 4B, ZOOM;
Real-time Zoom on B mode
-Image processing: Pre-processing, after-processing, dynamic range, frame rate, line average, edge; enhancement, Black/White inversion; Gray scale adjustment, contrast, brightness, γ revision.
-Gain: gain: adjustable between 0-100dB; Time gain control(TGC): 8 segment adjustment, B, M adjustment separately.
-Monitor: 12 inch high definition LCD screen(SS-10A) or 10 inch LCD screen(SS-10B)
-Supported output apparatus: U-Disk, Laser/ink printer, video printer, VGA
-Measurement and calculation(veterinary):
Cattle: BPD, CRL, TD; Horse: GA; Dog: GS; Cat: HD, BD; Sheep: BPD, CRL, TD
-Dimension: 300×230×85mm
-Probe Connector:2
-Weight: Around 2.3kg
After-sale service
We provide a good after-sale service to our partners, if has product fault need to repair, please contact us, and we will cooperate with your engineers to try to deal the fault in the local firstly, so as to minimize the transportation and other cost. We will guide you how to deal the troubleshooting, and your engineers follow our guidance to solve fault. If need parts for replacement, we will send to you. If still can not solve the fault at last, please arrange to deliver the fault parts back to us for repair.
And in warranty period, you should be responsible for the freight of sending the fault parts back to us(You can send by postal the freight is low, the time is long we can deliver new parts for your use). And we will be responsible for the cost of repair and the freight of sending new or after repair parts to you.
Thanks for visiting our website, any more question please don't hesitate to contact us, your inquiry will be highly appreciated.
