ST-1 Ultrasonic Thickness Gauge(NDT, Ultrasound, Ultrasonic, Measure)

ST-1 Ultrasonic Thickness Gauge(NDT, Ultrasound, Ultrasonic, Measure) thumbnail-1
ST-1 Ultrasonic Thickness Gauge(NDT, Ultrasound, Ultrasonic, Measure) photo-1
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
sonostar
Place of Origin:
Guangdong, China
Contact Supplier Request Quote Chat Now
Guangzhou Sonostar Technologies Co., Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name sonostar
Place of Origin Guangdong, China

Specifications

Easy to use, highly accurate
Can be measured fast, non-destructive and accurate resolution of 0.1 mm or 0.01

ST-1 ultrasonic thickness gauge made by our factory is a simple-to-use, highly accurate, hand-held ultrasonic thickness gauge with the operating principle of ultrasonic wave measuring. It can measure quickly, nondestructively and precisely with a resolution of 0.1mm or 0.01in. This instrument can be widely used in the fields such as manufacturing, metal processing, chemistry and business inspecting for measuring the thickness of all sorts of materials where ultrasonic wave can spread through with a constant speed and get the reflection from the back side. Apart from making accurate measure on various kinds of plates and processing components, it can also make detection on various kinds of pipes and pressure containers of the manufacturing facilities about their thickness loss after corrosion. ST-1 is an incensory specialized instrument for material protection.



Standard package:



ST-1 thickness gauge



Standard probe (PT-08)



Carrying case



Two 1.5V AA alkaline batteries



Couplant



Operating manual



Certification of quality



Packaging list



Operating principle:



Ultrasonic pulse/echo method with dual-element probes



Probe zero adjustment:



Selectable: 1-point calibration: normal measurement



          2-point calibration: curve surface measurement or other special application with a high precision



V-path correction:



Automatic



Measuring range:



0.8mm to 300mm; 0.031in to 11.81in



Depending on probe, material and surface condition



Digital resolution:



0.001in or 0.1mm



Units:



Selectable: inch or mm



Display:



128×64 dot-matrix LCD screen (1.65in×2.24in; 42mm×57mm)



EL backlight and switchable contract ratio



Digit height: 0.54in or 13.75mm



Measurement update rate:



4 Hz in standard measurement mode



25 Hz in MIN capture mode



Material velocity range:



1000 to 9999 m/s; 0.039 to 0.394 inch/µs



Power:



Two 1.5V AA alkaline batteries



Warning with low battery voltage



Operating time:



Up to 200 hours (without backlight) with alkaline batteries, depending on operating mode



Auto shut-off:



After 5 minutes of non-use



Operating temperature:



-10℃ to +50℃; +14℉ to +122℉



Specification to -20℃/-4℉ on request



Size:



5.86in×2.87in×1.25in; 149mm×73mm×32mm (H×W×D)



Weight:



200g; 7oz (including batteries)



Data logger capacity:



Up to 500 readings can be divided into a maximum of 5 files (user-selectable)



Optional accessories:



Attachable rubber case



Numerous special probes on request



Couplants and high-temperature couplant



4-step/6-step block for calibration



Data transmission cable



Application software



Operating language:



English and Chinese



Measuring error:



Up to 1in: ±0.002in or ±0.1mm



Above 1in: ± 1%H



H is the height of the testing object



Repeatability:



±0.001in or ±0.1mm



Application software:



UMVIEW



Interfaces:



Serial RS 232C port in combination with a communicative cable;



Data transfer parameters: 8 bits, 1 stop bit, 9600 baud, no parity.
