eu Mortise Door Lock From Onlense

eu Mortise Door Lock From Onlense photo-1
eu Mortise Door Lock From Onlense photo-2
eu Mortise Door Lock From Onlense photo-3
US$ 1 - 99 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Onlense
Model Number:
S200MF
Payment & Shipping
Payment Methods:
Port of Shipment:
Huangpu
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name Onlense
Model Number S200MF







Apartment key card lock with password keypad



S200MF apartment key card lock is a new kind of product made of zinc alloy material. Wireless system with remote control is available. Further more, Users can combine the open way: password keypad + mechanical key + Intelligent Card (Lifting up handle with deadolt to ensure more security). Its multiple function enjoys popular from clients with different countries. People can set 200 user group, which would be comvenient for people living together to user the same lock. The manager can set and delete user through operation.

eu mortise door lock from Onlense



 1. Specification of S200MFapartment key card lock



Brand  Onlense
Model S200MF
Material  Zinc alloy
Color Silver
Weight 2.5kg
Door thickness 30-55mm
Inductive  0cm
Working volt. 4.8-6.5VDC
Working temp. -20-70
Static current  ≤5uA
Working current  ≤200MA
Quantity of Button 12 buttons
Power supply   Batteries with 4 AA





More specific data of S200MF apartment key card lock

User quantity 200 sets
Left/right handle Available
Open way Password, IB card, Mechanical key
Deadbolt way Deadbolt by lifting up handle
User group key, card and key + card
Deadbolt way  Self-change easily
Backlight Adjustment as you need
Indication of flashes unproper open way  and low volt
Indication of sounds unproper open way  and low volt
Latches optional single latches and multiple latches
Application

password digital door lock for home, apartment and hotel



2.Advantages of S2000MF apartment key card lock

eu mortise door lock from Onlense

Free rotating handle



Handle with dissociative structure to increase strength

against outside force. Besides that, deadbolt by lifting up handle to ensure double  security to the apartment key card lock

              eu mortise door lock from Onlense

Multiple ways to open the door



User can choose different ways to open the door lock by IB card, keypad and mechanical key individually. What is more, those open ways can be combined with each other for apartment key card lock     (EG:card + keypad)

eu mortise door lock from Onlense

Backlight with the keypad



Users can choose to use backlight or not according to your need. It can be easily realized with reference to the introduction of operating manual.

eu mortise door lock from Onlense

Latches optional



There are two kinds of latches for option. And the Key latched ard made of 304 stainless steel material to have a longer lifespan.

eu mortise door lock from Onlense

Cylinder with cover



The cylinder is designed on the front panel, which is made of 304 stainless steel. The cover of cylinder can be more secure and beautiful

eu mortise door lock from Onlense

Easy to install apartment key card lock



Just remove the old one, then install the opening door lock with remote control  into the door drill. If it is a new project and new door for installation, operation with our manual as well.

eu mortise door lock from Onlense

The sealed gasket between two piece panels



The exquisite design and gasket has the function of anti-dust and anti-moist. It can be more suitable for apartment key card lock

eu mortise door lock from Onlense





3. Installation drawing of apartment key card lock

eu mortise door lock from Onlense







4.Certificate with apartment key card lock

eu mortise door lock from Onlense





5. Application of apartment key card lock
