Specifications
thick plastic sheetLow water absorption
2.non-sticking
3.Excellent self-lubrication
4.Super wear resistant
thick plastic sheet
What makes UHMW-PE such a distinctive and useful material? It's the combination of excellent properties – outstanding abrasion resistance, superior impact resistance, non-sticking and self-lubricating properties and excellent mechanical properties, even in cryogenic conditions.
Multi-colour UHMWPE Sheet
- abrasive resistance which always have in thermoelectricity polymer.
- best shock resistance even in low temperature.
- low frictional factor, and well sliding bearing material
- lubricity( no caking, in adhesion)
- best chemical corrosion resistance and stress craze resistance
- excellent machinery process ability
- lowest water absorption(<0.01%)
- paragon electric insulativity and antistatic behavior
- nice high energy radioactive resistance
- density is lower than other thermoplastics (< 1g/m3)
- long using temperature range: -269°C--90°C
20mm thickness sheet
Project name |
Unit |
Standard |
Impact strength |
KJ/m2 |
≥140 |
Water absorption |
% |
≤0.01 |
Compressive strength |
Mpa |
≥30 |
Ball indentation hardness |
N/mm2 |
≥20 |
Friction coefficient |
|
0.11-0.17 |
Abrasion loss |
G/cm2 |
3.8×10-4 |
Heat distortion temperature |
°C |
85°C |
Application
Because of its abrasion resistance, chemical resistance and good frictional properties, major application areas of UHMW-PE include bulk material handling, food and beverage machinery; chemical, mining and mineral processing equipment, recreational equipment, transportation and orthopedic implants.
Conveyor guide rails, belt scrapers, chain guides, suspension wear plates. These are just a few of the ways UHMW extrusions have been used over the years, with proven long-term results. Extruded UHMW profiles can save up to 50% of the cost of a machined profile.
Thanks to its extremely low coefficient of friction (0.14), the polymer easily outperforms steel in sliding applications. Its inherent lubricity minimizes the heat-generating friction, which gradually destroys steel parts, and ensures smooth, noiseless operation.
Withstands sand, grit, and corrosion at sub-zero temperatures.
UHMW extrusions have long been used as snow slides protecting the frame in snowmobile drive suspension systems--a tough endurance test for any material.
thick plastic sheet
