[RD-SDJ2400]Semi Automatic Twin Piece Corrugated Carton Box Stapler Machine

[RD-SDJ2400]Semi Automatic Twin Piece Corrugated Carton Box Stapler Machine thumbnail-1
[RD-SDJ2400]Semi Automatic Twin Piece Corrugated Carton Box Stapler Machine photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Other, Machinery & Hardware
Packaging Type:
Cartons
Contact Supplier Request Quote Chat Now
Pujiang Ruida Industry & Trade Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Other, Machinery & Hardware
Packaging Type Cartons
Packaging Material Plastic
Automatic Grade Semi-Automatic
Driven Type Electric
Power 3KW
Place of Origin Zhejiang, China
Brand Name RuiDa
Model Number RD-SDJ2400

Specifications

- Semi auto twin piece stitcher
- High quality and best service
- Competitive price
- Easy operation and maintenance

[RD-SDJ2400]Semi Automatic twin piece corrugated carton box stapler machine

Features:

  • The dual- purpose stitcher machine is able to nail monolithic carton, twin piece forming carton, and irregular carton.
  • Available for large carton stitching, the nail-feeding is convenient and quick with high efficiency.
  • The size adjustment is fully electric controlled, it could be changed within 2-3mins.
  • The strengthened nail, single nail, and double nail can be accomplished in a lump.
  • Equipped with auto counting function in the feeding unit, which is dedicated to the strapping of finished product.
  • Nail pitch is free adjusted and set by the screen between 30-120mm.
  • It's available to stitching the special carton without cover.
  • It's available to display the machine fault and fault cause on the screen.

Specification:

 [RD-SDJ2400]Semi Automatic twin piece corrugated carton box stapler machine



Model Unit RD-SDJ2400 RD-SDJ2700 RD-SDJ3000
Paper size(A+B)*2 Max mm 4800 5400 6000
Min mm 1060 1060 1060
Paper Length(A) Max mm 2250 2550 2850
Min mm 350 350 350
Paper width(B) Max mm 1200 1350 1500
Min mm 180 180 180
Paper height(C+D+C) Max mm 1800 1800 1800
Min mm 400 400 400
Min first stitching pitch(D) mm 25 25 25
Max TS width(E) mm 40 40 40
Stitching pitch mm 30-120 30-120 30-120
Qty. of stitching pcs 1-99 1-99 1-99
Speed stitch/min 350 350 350
Horsepower HP 18 18 18
Weight T 4 4 4.2
Overall dimension(L*W*H) mm 6000*3550*1800 6000*3550*1800 6000*4150*1800



[RD-SDJ2400]Semi Automatic twin piece corrugated carton box stapler machine
